Accessories for connecting to the PC programming terminal
Description
Use
Length
Reference
Weight
kg
From processor port
To PC port
PC terminal connection
cables
(
PC to PLC)
USB mini B port
BMX P34 1000/20
p
0/20
p
02
USB port
1.8
m
BMX XCA USB H018
0.065
4.5
m
BMX XCA USB H045
0.110
Mini-DIN port
Premium TSX 57 1
p
/2
p
/3
p
/4
p
RS 232D
(9-
way SUB-D
connector)
2.5
m
TSX PCX 1031
0.170
USB port
(
USB/RS 485
converter)
0.4
m
TSX CUSB 485
(1)
0.144
USB port
(
mini-DIN/
RJ45
cordset)
2.5
m
TSX CRJMD 25
(1)
0.150
Modbus port
15-
way SUB-D Quantum
140
CPU 311 10
140
CPU 434 12A
140
CPU 534 14A
RS 232D
(9-
way SUB-D
connector)
3.7
m
990
NAA 263 20
0.300
15
m
990
NAA 263 50
0.180
USB port
Premium TSX 57 5
p
/6
p
Quantum 140 CPU 6
p
1
USB port
3.3
m
UNY XCA USB 033
–
Modbus port, RJ45 connector
Quantum 140 CPU 6
p
1
RJ 45
connector
1
m
110
XCA 282 01
–
3
m
110
XCA 282 02
–
6
m
110
XCA 282 03
–
PC terminal connection
cables
(
PC SUB-D to Modicon STB
I/O)
HE13 connector Modicon STB
I/O network interface module
(
NIM)
RS 232D
(2)
(9-
way SUB-D
connector)
2
m
STB XCA 4002
0.210
USB/SUB-D adaptor
(
PC USB to Modicon STB
I/O)
HE13 connector Modicon STB
I/O network interface module
(
NIM) with STB XCA 4002
cable
(3)
USB port
(3)
–
SR2 CBL 06
0.185
Description
Use
Reference
Weight
kg
Universal Bluetooth
®
interface (UBI)
Provides Bluetooth
®
connectivity for products such as the
Modicon M340/Premium platforms and Altivar/Lexium servo
drives, via their serial port (RS 485).
Used for setting-up and maintenance of products.
Designed for permanent installation and can be safely fitted on
the inside or outside of electrical enclosures.
b
Protocols supported: Modbus and Uni-Telway
b
Powered via the product’s RS 485 serial port
b
Max. range in direct line of sight: 20 m
The kit comprises:
b
AUniversal Bluetooth
®
interface (UBI)
b
An RJ45/mini-DIN cable (length 1 m)
b
An RJ45/RJ45 cable (length 1 m)
b
A fixing clamp for installation inside the electrical enclosure
b
ACD with configuration software and user manual
TCS WAAC 13FB
0.320
(1)
The
TSX CUSB 485
converter requires use of the
TSX CRJMD 25
mini-DIN/RJ45 cordset.
(2)
For connection on a USB port, the
SR2 CBL 06
cable must also be used (3).
(3)
Adaptor equipped with a USB connector (PC side) and a 9-way SUB-D connector (
STB XCA 4002
cable side); requires the
STB XCA 4002
cable (9-way SUB-D/HE 13) for connection to the HE13 connector on the Modicon STB NIM.
TSX PCX 1031
BMX XCA USB H0
pp
Selection guide:
page 6/2
TSX CUSB485
TCS WAAC 13FB
References
(
continued)
Software
Unity Pro software
Small/Medium/Large/Extra Large
