ConneXium unmanaged switches, twisted pair
Presentation
Switches are used to increase the limits of architectures based on hubs or
transceivers, by separating collision domains.
Higher layer communication is provided between the ports, and collisions at link
layer are not propagated (filtering).
They therefore improve performance by better allocation of the bandwidth due to
the reduction of collisions and network load.
Certain ConneXium switch models also enable redundant architectures to be
created on twisted pair copper ring or optical fibre.
Unmanaged switches are plug and play devices that do not need to be configured
by the user. Certain models can also be managed remotely via SNMP or HTTP
protocols for monitoring and diagnostic purposes.
DTE
DTE
DTE
DTE
DTE
DTE
DTE
DTE
DTE
DTE
DTE
DTE
DTE
DTE
DTE
DTE
DTE
DTE
DTE
DTE
DTE
100
Mbps
fibre-optic ring
Collision
domain 1
Collision
domain 2
Collision
domain 3
Reference
Description
Interfaces
Reference
Weight
kg
ConneXium unmanaged
switches
5
x 10BASE-T/100BASE-TX
ports (copper cable), shielded
M12 type D connectors, IP67
TCS ESU 051F0
0.210
8
x 10BASE-T/100BASE-TX
ports (copper cable), RJ45
shielded connectors, IP20
499
NES 181 00
0.230
8
x 10BASE-T/100BASE-TX
ports (copper cable), RJ45
shielded connectors, IP30
TCS ESU 083FN0
0.246
Description
With connectors
at both ends
Length Reference
Weight
kg
IP67 power supply cables
(
for ConneXium switch
TCS ESU 051F0
)
Female M12
straight connector
0.230
kg
XZC P1164L2
–
5
m
XZC P1164L5
–
Female M12
elbowed connector
2
m
XZC P1264L2
–
5
m
XZC P1264L5
–
IP67 power supply
connectors
(
for ConneXium switch
TCS ESU 051F0
)
Female M12
straight connector
–
XZC C12 FDM 50B
–
Female M12
elbowed connector
–
XZC C12 FCM 50B
–
499
NES 181 00
TCS ESU 051F0
Selection guide:
Pages 5/50 ...
Presentation,
references
Ethernet network
Wiring system
ConneXium unmanaged switches
