Selection guide:
Pages 5/50 ...
Glass fibre optic cables
Glass fibre optic cables are intended for connection:
b
To terminal devices (DTE)
b
Between hubs, transceivers and switches
Description
With connectors
at both ends
No.
Length
Reference
Weight
kg
Glass fibre optic cables
1
SC connector
1
MT-RJ connector
5
5
m
490
NOC 000 05
–
1
ST (BFOC) connector
1
MT-RJ connector
6
5
m
490
NOT 000 05
–
2
MT-RJ connectors
7
3
m
490
NOR 000 03
–
5
m
490
NOR 000 05
–
Separate parts for TCS ESM and TCS ESB switches
Description
Optical fibre
Type
Reference
Weight
kg
Fibre optic modules for
Gigabit ports
with LC connector
(1)
Multimode 50/125 μm or 62.5/125 μm
1000
BASE
-
SX
TCS EAA F1LFU00
0.040
Single mode 9/125 μm
1000
BASE
-
LH
TCS EAA F1LFH00
0.040
Multimode 50/125 μm or 62.5/125 μm
Single mode 62.5/125 μm
1000
BASE
-
LX
TCS EAA F1LFS00
0.040
Description
Use
Port
Reference
Weight
kg
Configuration backup key
for TCS ESM switches
Connected on the front
of the switch, used to:
-
Save and retrieve the switch configuration
-
Update the internal software
USB
TCS EAM 0100
–
Configuration backup key
for TCS ESB switches
RJ45 (V24)
TCS EAM 0200
–
Connection components for IP 67 switch
Description
With connectors
at both ends
No.
Length
Reference
Weight
kg
Straight-through copper
cables
1
x IP 67 4-way M12 connector
and 1 x RJ45 connector
8
1
m
TCS ECL 1M3M 1S2
–
3
m
TCS ECL 1M3M 3S2
–
10
m
TCS ECL 1M3M 10S2
–
25
m
TCS ECL 1M3M 25S2
–
40
m
TCS ECL 1M3M 40S2
–
2
x IP 67 4-way M12
connectors
–
1
m
TCS ECL 1M1M 1S2
–
3
m
TCS ECL 1M1M 3S2
–
10
m
TCS ECL 1M1M 10S2
–
25
m
TCS ECL 1M1M 25S2
–
40
m
TCS ECL 1M1M 40S2
–
Power supply cables
2
female M12
straight connectors
–
2
m
XZC P1164L2
–
5
m
XZC P1164L5
–
2
female M12
elbowed connectors
–
2.5
m
XZC P1264L2
–
5
m
XZC P1264L5
–
2
female M12
straight connectors
–
–
XZC C12 FDM 50B
–
2
female M12
elbowed connectors
–
–
XZC C12 FCM 50B
–
M12/RJ45 adaptor
IP 67 4-way female M12 connector
and female RJ45 connector
–
–
TCS EAA F11F13F00
–
(1)
Dimensions: Wx H x D= 20 x 18 x 50mm
490
NOT 000 05
490
NOR 000 05
490
NOC 000 05
References
(
continued)
Ethernet network
Wiring system
ConneXium connection components
