Shielded copper connection cables
ConneXium shielded connection cables are available in two versions to meet the various current standards and
approvals:
b
EIA/TIA 568 shielded twisted pair cables for
e
market
These cables conform to:
v
EIA/TIA-568 standard, category CAT 5E
v
IEC 11801/EN 50173-1 standard, class D
Their fire resistance conforms to:
v
NF C32-070 standard, class C2
v
IEC 322/1 standards
v
Low Smoke Zero Halogen (LSZH)
b
EIA/TIA 568 shielded twisted pair cables for UL market
These cables are:
v
CEC type FT-1
v
NEC type CM
A new range of ConneXium fully shielded preassembled cables has been specially designed for use in harsh
industrial environments. These cables combine a category 5E shielded cable and RJ45 connectors reinforced
with a metal profile.
EIA/TIA 568 shielded twisted pair cables for
e
market
Description
With connectors
at both ends
No.
Type
Length
Reference
Weight
kg
Straight-through
copper cables
e
compatible
2
x RJ45 connectors
For connection to
terminal equipment
(
DTE)
1
Standard 2 m
490
NTW 000 02
–
5
m
490
NTW 000 05
–
12
m
490
NTW 000 12
–
40
m
490
NTW 000 40
–
80
m
490
NTW 000 80
–
Ruggedized 1 m
TCS ECE 3M3M1S4
–
2
m
TCS ECE 3M3M2S4
–
3
m
TCS ECE 3M3M3S4
–
5
m
TCS ECE 3M3M5S4
–
10
m
TCS ECE 3M3M10S4
–
Crossover copper
cables
e
compatible
2
x RJ45 connectors
For connection between
hubs, switches and
transceivers
2
Standard 5 m
490
NTC 000 05
–
15
m
490
NTC 000 15
–
40
m
490
NTC 000 40
–
80
m
490
NTC 000 80
–
Shielded twisted pair cables for UL market
Description
With connectors
at both ends
No.
Type
Length
Reference
Weight
kg
Straight-through
copper cables
UL compatible
2
x RJ45 connectors
For connection to
terminal equipment
(
DTE)
3
Standard 2 m
490
NTW 000 02U
–
5
m
490
NTW 000 05U
–
12
m
490
NTW 000 12U
–
40
m
490
NTW 000 40U
–
80
m
490
NTW 000 80U
–
Ruggedized 1 m
TCS ECU 3M3M1S4
–
2
m
TCS ECU 3M3M2S4
–
3
m
TCS ECU 3M3M3S4
–
5
m
TCS ECU 3M3M5S4
–
10
m
TCS ECU 3M3M10S4
–
Crossover copper
cables
UL compatible
2
x RJ45 connectors
For connection between
hubs, switches and
transceivers
4
Standard 5 m
490
NTC 000 05U
–
40
m
490
NTC 000 40U
–
80
m
490
NTC 000 80U
–
Do it Yourself copper cable and connectors
The ConneXium Do it Yourself offer consists of 2 references for connectors (M12 and RJ45) and 1 cable
reference (300 m coil), enabling Ethernet 10/100 Mbps networks to be cabled in the field.
The maximum length of cables created in this way is 80 m.
They are quick to assemble using a knife and simple wire cutters (no special tools are required).
Description
Characteristics
Length
Reference
Weight
kg
Ethernet copper cable
2
shielded twisted pairs
24
AWG
Conforms to the standards
and approvals listed above
300
m
CS ECN 300R2
–
RJ45 connector
Conforms to EIA/TIA-568-D
–
TCS EK3 MDS
–
M12 connector
Conforms to IEC 60176-2-101
–
TCS EK1 MDRS
–
References
Ethernet network
Wiring system
ConneXium connection components
TCS EC
p
3
M3M
pp
S4
2
1
3
4
5
6
7
8
9
10
