Selection Guide
Premium platforms for PL7 software offer
TSX 57 1
p
processors
TSX 57 2
p
processors
Number of racks
(
according to rack type)
4
with 4, 6, 8 slots or 2 with 12 slots
16
with 4, 6, 8 slots or 8 with 12 slots
In-rack I/O
(1)
Discrete I/O
512
channels (8-, 16-, 32- or 64-channel module)
1024
channels (8-, 16-, 32- or 64-channel module)
Analog I/O
24
channels (4-, 8- or 16-channel module)
80
channels (4-, 8- or 16-channel module)
Integrated process control
–
Configurable loops (10 channels with 3 loops
max.)
In-rack application-
specific channels
Max. no. of channels
8
24
Counter
Modules with 2/4 counter channels 1 MHz max., single-channel electronic cam module
Motion
(2)
Modules with 1/2 axes for stepper motors, 2/3/4 axes for analog control servo motors, 8/16 axes
with SERCOS digital link
Weighing
Module for 8 load cells (2 application-specific channels)
Serial links
In-rack communication modules (1 application-specific channel)
Serial link connections
Modbus
RS 232, RS 485 or current loop
(3)
(4)
master/slave PCMCIAmodules and RS 485 master/ slave
in-rack communication modules
Uni-Telway
1
integrated RS 485 master/slave channel
(5)
,
RS 232, RS 485 or current loop
(3)
(4)
master/slave
PCMCIAmodules and RS 485 master/slave in-rack communication modules
Character mode
1
integrated RS 485 channel
(5)
,
RS 232, RS 485 or current loop
(3) (4)
PCMCIAmodules and
RS 485 in-rack communication modules
Bus connections
Actuator/sensor bus
AS-Interface master V2
2
in rack modules
4
in rack modules
CANopen machine bus
master V4.02
(6)
1
PCMCIAmodule
(3)
NTER
B
US
field bus master V2
(6)
or Profibus DP master V0
Class 1 and 2
(6)
–
1
in-rack module
Network connections
Max. no. of networks
1
1
Ethernet Modbus/TCP
Multiprotocol in-rack modules (Modbus, Uni-TE, Global Data, I/O Scanning, TCP Open), Web
server, FactoryCast service and Factory Cast HMI services
Communication modules
Fipway
(3)
(4)
and Modbus Plus
(3)
PCMCIAmodules, in-rack Ethway modules
Memory capacity
Without PCMCIA extension
32
Kwords program and data
48/64
Kwords program and data
(7)
With PCMCIA extension
32
Kwords data
64
Kwords program
48/64
Kwords data
(7)
160
Kwords program
Data storage
128
Kwords
640
K words + 2048 K words
Symbol storage
–
128
Kwords
Power supply
100…240
V
a
, 24
V
c
non-isolated and 24…48 V
c
isolated power supply modules. A power
supply is required for each rack.
Consumption
See page 9/6
Standards and certifications
See pages 9/8 and 9/18
Premium processor
type
(8)
Standard
TSX P57 103M
TSX P57 203M
Q
g
Integrated Ethernet
TSX P57 2623M
Q
(10)
g g
Integrated Fipio
TSX P57 153M
(9)
TSX P57 253M
Q
Integrated Ethernet and Fipio
TSX P57 2823M
(10)
Pages
1/19
(1)
The maximum values for the number of discrete I/O, analog I/O and process control channels are cumulative.
(2) 1
axis = 1 application-specific channel, except for SERCOS modules where, depending on the configuration, the module = 2…32 channels.
(3)
Module to be inserted into the lower PCMCIA slot (no. 1) on the Premium processor.
(4)
Module to be inserted into the PCMCIA slot on the
TSX SCY 21 601
in-rack communication module.
(5)
Non-isolated serial link. For distances > 10 m, use connection accessory
TSX PACC 01
,
see pages 5/131 and 5/133.
(6)
Reduce the number of modules permitted (I
NTER
B
US
or Profibus DP) by 1 when CANopen is used.
(7)
The second value corresponds to the processor with integrated Fipio bus manager link.
Modicon Premium automation
platform
Premium processors
