Presentation
Transparent Ready products allow transparent communication on a single Ethernet
Modbus/TCP network.
In addition to universal Ethernet services (HTTP, BOOTP/DHCP, FTP, etc.),
the Transparent Ready device communication services designed for use in
automation applications include:
b
Modbus/TCP messaging for class 10, 20 or 30 devices
b
I/O Scanning service for class 30 devices
b
FDR (Faulty Device Replacement) for class 10, 20 or 30 devices
b
SNMP
(
Simple Network Management Protocol)
network management for class 20
or 30 devices
b
Global Data, for class 30 devices
b
Bandwidth management for class 30 devices
b
NTP (Network Time Protocol) time synchronization for class 30 devices
b
E-mail alarm notification via SMTP server for class 30 devices
b
TCP Open, optional, for class 30 devices
Note
:
The above services are listed for general information. Please refer to the characteristics
pages for each device for exhaustive details of which services are supported by each one.
The following pages present the various options available through all of these
services in order to facilitate the optimum choice of solutions when defining a system
integrating Transparent Ready devices.
Services
Applica-
tions
Transport
Link
Physical
Network
manage-
ment
Global
Data
FDR (Faulty Device Replacement)
Web
server
Messaging I/O
Scanning
SNMP
RTPS DHCP
TFTP
FTP
HTTP
Modbus
UDP
TCP
IP
Ethernet 802.3 and Ethernet II
MIB Transparent Ready
TCP Open
SMTP
Time
synchro-
nization
NTP
Presentation
Modicon Premium automation
platform
0
Ethernet Modbus/TCP network
Ethernet Modbus/TCP communication services
MIB 2 standard
