The IP and IK degrees of protection provided by an enclosure must be specified as
a function of the various external influences defined by standard IEC 30364-5-51, in
particular:
presence of foreign solid bodies (code AE)
presence of water (code AD)
mechanical stress (code not specified)
capability of persons (code BA)
....
Prisma Plus switchboards are designed for indoor installation.
Unless the rules, standards and regulations of a specific country stipulate otherwise,
Schneider Electric recommends the following IP and IK values based on French
guide UTE C 15-103 (March 2004).
b
b
b
b
b
Using the table
1
Opposite the relevant premises, read the recommended IP and IK values.
2
The
b
symbol indicates the enclosure or cubicle satisfying the criteria of the UTE
guide.
Any enclosure or cubicle with a higher degree of protection can also be used.
3
If several degrees of protection are possible (refer to the standard for more details)
and the
v
and
b
symbols are indicated (e.g. 24
v
/25
b
), enclosures that correspond
to the higher degree of protection (
b
) are suitable for the lower degree of
protection (
v
).
Example:
Selection of an enclosure for a laundry room.
Minimum degree of protection: IP21/IK02
Awall-mount enclosure with a door (plain or transparent), a canopy and a gasket
offer IP31/IK08 degrees of protection and are therefore suitable for this application.
Type of premises
Enclosure or cubicle
Wall-mounted
enclosure
without door
with door
with door + canopy with door + canopy
+ gasket
IP55
Floor-standing
enclosure
without door
with door
with door + canopy with door + canopy
+ gasket
Cubicle
with fixed frame with door + IP30
cover
with door + gasket
+ IP30 cover
with door + IP55
cover
Min. IP/IK
required
IP30/IK07
IP30/IK08
IP31/IK08
IP43/IK08
IP55/IK10
IP IK
Domestic or comparable premises or locations
Porch
24
07
b
Bathrooms (see washrooms)
Bicycles, motorcycles, tricycles, etc.
(premises for)
20
07
b
Water, sewer and hea ing
connections
23
02
b
Laundries
21
02
b
Cellars, garages, furnace rooms
20
02/07
b
Bedrooms
20
02
b
Trash rooms
25
07
b
Halls in cellars
20
07
b
Courtyards
24/25 02/07
b
Kitchens
20
02
b
Shower rooms (see washrooms)
Indoor stairways and alleys
20
02/07
b
Outdoor stairways and outdoor alleys
without roofs
24
07
Outdoor alleys with roofs
21
02
b
Attics (roof space)
20
02
b
Garden shelters
24/25 02/07
b
Latrines
20
02
b
Dustbin rooms
25
02/07
b
Ironing room
20
02
b
Access ramps to garages
25
07
b
Selection of enclosures
according to the premises
Additional informations
Enclosure characteristics
