Monitor electrical network
status
Local supervision
Switchboard display units
Energy efficiency with Prisma Plus
Switchboard display units are a simple, low-cost
solution for basic monitoring of electrical switchboards.
They can be rapidly installed for direct readout of data
through specially designed front plates.
FDM121 switchboard display unit for Compact NSX
The FDM121 displays the measurement, alarm and operating information of the
intelligent functional unit.
Two possibilities for door installation
Surface mounting using a fixing accessory (requires door drilling).
Installation in door cutout using clips.
Installation on metal front plates with cutouts
b
b
PD391291-57
Designation
Cat. no.
Metal front plate with cut-outs, 3 modules (for four 96 x 96 mm devices)
03911
Blanking plate (for 96 x 96 mm hole)
03908
DD381711
PE86158-37
PowerMeter switchboard display
PowerMeter devices are compatible with all intelligent functional units via their
Modbus communication port (except Compact NSX) and can also be used as an
interface between the communication gateway and the intelligent device to combine
both local and remote monitoring.
Installation on metal front plates with cutouts
Designation
Cat. no.
Metal front plate with cut-outs, 3 modules (for one 96 x 96 device)
03913
DD383662
