C-shaped cable-tie supports
C-shaped longitudinal and lateral cable-tie supports
1600 mm long support that can be cut to length as needed.
Can be secured to:
universal angle bracket 03581 (for the longitudinal support)
universal angle bracket 03582 (for the lateral support)
modular rail 03593 (for depth adjustment).
b
b
b
DD383425
Designation
Cat. no.
Cable-tie support
L = 1600 mm
08783
Supplied with hardware for mounting on universal angle brackets and modular rails.
Cables can be attached by ties or clamps.
Universal cross-members
Longitudinal cross-members
Set of two longitudinal cross-members, L = 650 mm.
They are connected directly to the framework (W = 650 mm or 650 + 150 mm).
They can also be mounted on the lateral cross-members (see opposite).
They are used to position and support the cables of an incoming device.
Lateral cross-members
They are connected directly to the uprights of the framework.
They offer numerous positioning holes and can be used to adjust the depth of
longitudinal cross-members.
There are two lengths:
Set of two lateral cross-members, L = 400 mm for frameworks that are 400 mm
deep
Set of two lateral cross-members, L = 200 mm, can be added to the 400 mm cross-
members for frameworks that are 600 mm deep. They can also be installed
separately.
b
b
DD381316
Designation
Cat. no.
Set of two lateral cross-
members
L = 400 mm
03584
L = 200 mm
03586
Set of two longitudinal
cross-members
L = 650 mm
03587
