Distribution
Terminal blocks
Terminal blocks for 35 to 150
v
cables, flexible or rigid, without a metal ferrule.
Complementary offer “terminal blocks spring technology” for cables up to 16
v
.
two colours: grey for phases, blue for neutral
mounting by clipping onto a modular rail
rated insulation level:
terminal blocks for 35 to 70
v
cables: Ui = 800 V
terminal blocks for 150
v
cables: Ui = 1000 V
rated impulse withstand voltage:
terminal blocks for 35 to 150
v
cables: Uimp = 8 kV.
b
b
b
v
v
b
v
501685
Terminal blocks for 35
v
cables
16 mm wide
Number per set
Cat. no.
Grey block
2 x 35
v
20
AB1 VVN3535U
Blue block
2 x 35
v
20
AB1 VVN3535UBL
Commoning link
2 pole
10
AB1 ALN352
501686
Terminal blocks for 70
v
cables
24 mm wide
Number per set
Cat. no.
Grey block
2 x 70
v
20
AB1 VVN7035U
Blue block
2 x 70
v
20
AB1 VVN7035UBL
Commoning link
2 pole
10
AB1 ALN702
501687
Terminal blocks for 150
v
cables
28 mm wide
Number per set
Cat. no.
Grey block
2 x 150
v
10
AB1 VVN15035U
Blue block
2 x 150
v
10
AB1 VVN15035UBL
Commoning link
2 pole
10
AB1 ALN1502
