132 / 356
A-80
Functional units
Universal cross-members
Longitudinal cross-members
Set of two longitudinal cross-members, L = 650 mm.
They are connected directly to the framework (W = 650 mm or 800 mm (650 +
150 mm).
They can also be mounted on the lateral cross-members (see opposite).
They are essentially used to position and support the cables of an incoming device
or to install all types of devices.
Lateral cross-members
They are connected directly to the framework.
They offer numerous positioning holes and can be used to adjust the depth of
longitudinal cross-members.
There are two lengths:
Set of two lateral cross-members, L = 400 mm for frameworks that are 400 mm
deep
Set of two lateral cross-members, L = 200 mm, can be added to the 400 mm cross-
members for frameworks that are 600 mm deep. They can also be installed
separately.
Cat. no. selection
b
b
DD381173
Longitudinal cross-members attached directly to the
framework.
DD381316
Designation
Cat. no.
Set of two lateral cross-
members
L = 400 mm
03584
L = 200 mm
03586
Set of two longitudinal
cross-members
L = 650 mm
03587
Longitudinal cross-members mounted on lateral cross-
members, L = 400 mm.
DD381580
Creation of a platform with two lateral and two longitudinal
cross-members.
DD381581
Set of two lateral cross-members, L = 200 mm.
Other devices
Mounting on lateral and longitudinal
cross-members
Others
