Power breakers - Tmax moulded case circuit breakers

42 / 44

42 Moulded Case Breakers 0115 ABB Low Voltage
Shrouds and terminals
Extended spread front terminals
Product Hierarchy 3000009
Order Code
KIT ES XT2 3 poles 1SDA066893R1
KIT ES XT3 3 poles 1SDA066897R1
KIT ES XT4 3 poles 1SDA066901R1
KIT ES XT2 4 poles 1SDA066894R1
KIT ES XT3 4 poles 1SDA066898R1
KIT ES XT4 4 poles 1SDA066902R1
Extended spread front terminals Product Hierarchy 3000006
KIT ES T5 3 poles 1SDA055040R1
KIT ES UP T6 - S6 3 poles 1SDA050692R1
KIT ES LO T6 - S6 3 poles 1SDA050704R1
KIT ES T7-T7M 3 poles UPP 1SDA063107R1
KIT ES T7-T7M 3 poles LOW 1SDA063108R1
KIT ES T5 4 poles 1SDA055041R1
KIT ES T6 - S6 4 poles 1SDA050693R1
KIT ES T7-T7M 4 poles 1SDA063109R1
Terminals for Cu cables Product Hierarchy 3000009
KIT FC Cu XT2 3 poles 1SDA066909R1
KIT FC Cu XT3 3 poles 1SDA066913R1
KIT FC Cu XT4 3 poles 1SDA066917R1
KIT FC Cu XT2 4 poles 1SDA066910R1
KIT FC Cu XT3 4 poles 1SDA066914R1
KIT FC Cu XT4 4 poles 1SDA066918R1
Terminals for Cu cables Product Hierarchy 3000006
KIT FC Cu 1x240mm2 T5 400 3 poles 1SDA055016R1
Kit FC Cu 2x240mm2 T5 630 3 poles 1SDA055364R1
KIT RC 2x150mm2 T6 630 3 poles 1SDA023381R1
KIT 1/2 3p F F>F RC T6 800 1SDA023385R1
KIT FC Cu 1x240mm2 T5 400 4 poles 1SDA055017R1
Kit FC Cu 2x240mm2 T5 630 4 poles 1SDA055365R1
KIT RC 2x150mm2 T6 630 4 poles 1SDA023391R1
KIT RC 3x240mm2 T6 800 4 poles 1SDA023395R1
Rear adjustable terminals Product Hierarchy 3000009
KIT R XT2 3 poles 1SDA066941R1
KIT R XT3 3 poles 1SDA066945R1
KIT R XT4 3 poles 1SDA066949R1
KIT R XT2 4 poles 1SDA066942R1
KIT R XT3 4 poles 1SDA066946R1
KIT R XT4 4 poles 1SDA066950R1
Rear adjustable terminals Product Hierarchy 3000006
KIT R T5 3 poles 1SDA055044R1
KIT R T6 3 poles 1SDA060425R1
KIT R T7-T7M 3 poles 1SDA063116R1
KIT R T5 4 poles 1SDA055045R1
KIT R T6 4 poles 1SDA060426R1
Rear horizontal connectors Product Hierarchy 3000006
KIT HR T7-T7M 3 poles 1SDA063120R1
KIT HR T7-T7M 4 poles 1SDA063121R1
Rear vertical connectors Product Hierarchy 3000006
KIT VR T7-T7M 3 poles 1SDA063124R1
KIT VR T7-T7M 4 poles 1SDA063125R1
Power distribution MCCBs
Type XT1 ... XT4 & T1 ... T7 accessories
