40 Moulded Case Breakers 0115
ABB Low Voltage
Shrouds and terminals
High shields
Product Hierarchy 3000009
Order Code
XT1 3P High Terminal shields (Pair) - HTC
1SDA066664R1
XT1 4P High Terminal shields (Pair) - HTC
1SDA066665R1
XT2 3P High Terminal shields (Pair) - HTC
1SDA066666R1
XT2 4P High Terminal shields (Pair) - HTC
1SDA066667R1
XT3 3P High Terminal shields (Pair) - HTC
1SDA066668R1
XT3 4P High Terminal shields (Pair) - HTC
1SDA066669R1
XT4 3P High Terminal shields (Pair) - HTC
1SDA066670R1
XT4 4P High Terminal shields (Pair) - HTC
1SDA066671R1
High shields
Product Hierarchy 3000006
T5 3P High Terminal Shields (Pair)
1SDA054960R1
T5 4P High Terminal Shields (Pair)
1SDA054961R1
T6 3P High Terminal Shields (Pair)
1SDA014040R1
T6 4P High Terminal Shields (Pair)
1SDA014041R1
T7/T7M 3P High Terminal Shields (Pair)
1SDA063091R1
T7/T7M 4P High Terminal Shields (Pair)
1SDA063092R1
Low shields
Product Hierarchy 3000009
XT1 3P Low Terminal shields (Pair) - HTC
1SDA066655R1
XT1 4P Low Terminal shields (Pair) - HTC
1SDA066656R1
XT2 3P Low Terminal shields (Pair) - HTC
1SDA066657R1
XT2 4P Low Terminal shields (Pair) - HTC
1SDA066659R1
XT3 3P Low Terminal shields (Pair) - HTC
1SDA066660R1
XT3 4P Low Terminal shields (Pair) - HTC
1SDA066661R1
XT4 3P Low Terminal shields (Pair) - HTC
1SDA066662R1
XT4 4P Low Terminal shields (Pair) - HTC
1SDA066663R1
Low shields
Product Hierarchy 3000006
T5 3P Low Terminal Shields (Pair)
1SDA054968R1
T5 4P Low Terminal Shields (Pair)
1SDA054969R1
T6 3P Low Terminal Shields (Pair)
1SDA014038R1
T6 4P Low Terminal Shields (Pair)
1SDA014039R1
T7/T7M 3P Low Terminal Shields (Pair)
1SDA063093R1
T7/T7M 4P Low Terminal Shields (Pair)
1SDA063094R1
Phase barriers
Product Hierarchy 3000006
PB100 T4-5-T7-X1 3p PART.DIV.PHA.LOW
1SDA054970R1
PB100 T4-5-T7-X1 4p PART.DIV.PHA.LOW
1SDA054971R1
PB200 T4-5-7-T7M-X1 3p PART.DIV.PHA.HIGH
1SDA054972R1
PB200 T4-5-7-T7M-X1 4p PART.DIV.PHA.HIGH
1SDA054973R1
Extended front terminals
Product Hierarchy 3000009
KIT EF XT1 3 poles
1SDA066865R1
KIT EF XT2 3 poles
1SDA066869R1
KIT EF XT3 3 poles
1SDA066873R1
KIT EF XT4 3 poles
1SDA066877R1
KIT EF XT1 4 poles
1SDA066866R1
KIT EF XT2 4 poles
1SDA066870R1
KIT EF XT3 4 poles
1SDA066874R1
KIT EF XT4 4 poles
1SDA066878R1
Extended front terminals
Product Hierarchy 3000006
KIT EF T5 3 poles
1SDA055036R1
KIT EF T6 630 3 poles
1SDA023379R1
KIT EF T6 800 3 poles
1SDA023383R1
KIT EF T7-T7M-X1 3 poles
1SDA063103R1
KIT EF T5 4 poles
1SDA055037R1
KIT EF T6 630 4 poles
1SDA023389R1
KIT EF T6 800 4 poles
1SDA023393R1
KIT EF T7-T7M-X1 4 poles
1SDA063104R1
Power distribution MCCBs
Type XT1 ... XT4 & T1 ... T7 accessories
7
/53
1SDC210033D0202
DIN Guide
RCQ020/A 415V AC
065980
Toroid closed Ø 60mm
037394
Toroid closed Ø 110mm
037395
Toroid closed Ø 185mm
050543
Installation
Bracket for fixing onto DIN rail
Type
1SDA…R1
3 poles
4 poles
KIT DIN50022
066653
066653
Terminals
Insulating Terminal Cover
Type
1SDA…R1
3 poles
4 poles
LTC Low terminal covers
066662
066663
HTC High terminal covers
066670
066671
Sealable screws for Terminal Covers
Type
1SDA…R1
2 pcs
Kit with two sealable screws
066672
Phase Separators
Type
1SDA…R1
4 pcs
6 pcs
PB Height 25mm
069062
069063
PB Height 100mm
066675
066680
PB Height 200mm
066677
066682
Terminal cover
Sealable screw
Phase separators
