38 Moulded Case Breakers 0115
ABB Low Voltage
Power distribution MCCBs
Type Tmax XT1 ... XT4 & T1 ... T7 accessories
Operating mechanism and locks
Padlock lever lock PPL
Breaker
Product Hierarchy 3000009
Order Code
PLL - removable lock with padlocks in open position
XT1-XT3
1SDA066588R1
PLL - fixed lock with padlocks in open position
1SDA066589R1
PLL - fixed lock with padlocks in open/close position
1SDA066591R1
PLL - fixed lock with padlocks in open position
XT2-XT4
1SDA066590R1
PLL - fixed lock with padlocks in open/close position
1SDA066592R1
Padlock lever lock PPL
Product Hierarchy 3000006
PLL - padlock pushbutton in open position
T7 pushbutton opp.
1SDA062151R1
PLL - padlock lever in open position
T7 toggle
1SDA062150R1
Key locks KLC
Product Hierarchy 3000009
KLC BL.Ronis locked in open position
XT1
1SDA066593R1
KLC BL.Ronis locked in open position
XT2-XT4
1SDA066599R1
KLC BL.Ronis locked in open position
XT3
1SDA066605R1
Key locks KLC
Product Hierarchy 3000006
KLC-D key lock service operation
T7
1SDA062134R1
KLC key lock Ronis operater adapter
1SDA062139R1
KLC key lock Profalux operater adapter
1SDA062140R1
Key locks front/rotary handle KLF
Product Hierarchy 3000006
KLF-D different keys
T4-T5
1SDA054939R1
KLF-S same keys
1SDA054940R1
KLF-D dfferent keys
T6
1SDA060658R1
KLF-S key lock EQ.20005
1SDA060659R1
Key locks extended rotary handle shaft
Product Hierarchy 3000009
Castell lock adapter
XT1-XT2-XT3
OETLZW16
XT4-T7
OETLZW5
Key locks motor operator MOL
Product Hierarchy 3000006
MOL-D different keys
T4-T5
1SDA054904R1
T6
1SDA060611R1
MOL-S same key for different groups (N.20005)
T4-T5
1SDA054905R1
T6
1SDA060612R1
MOL-M manual operation same key
T4-T5
1SDA054909R1
T6
1SDA060616R1
Key lock in open position on the circuit breaker pushbutton operated
Product Hierarchy 3000006
KLC-D key lock service operation
T7 Pushbutton opp.
1SDA062141R1
KLC Ronis-Profalux
1SDA062146R1
Key lock on handle
Product Hierarchy 3000009
RHL Ronis dfferent keys
XT1-XT4
1SDA066617R1
RHL Ronis Type A
1SDA066618R1
Key lock in racked-in/test isolated/rack-out position
Product Hierarchy 3000006
Arrangement for Ronis key lock - can be equipped with two different keys T7
1SDA063567R1
Arrangement for Profalux key lock T7
1SDA063570R1
Arrangement for Castell key lock T7
1SDA063568R1
Arrangement for Kirk key lock T7
1SDA063569R1
Front lock device
Product Hierarchy 3000009
FLD XT2-XT4 F/P
1SDA066635R1
FLD XT2-XT4 W
1SDA066636R1
FLD T4-T5 F/P
1SDA054944R1
Front lock device
Product Hierarchy 3000006
FLD T4-T5 W
1SDA054945R1
FLD T6 F/P
1SDA060417R1
FLD T6 W
1SDA060418R1
7
/51
1SDC210033D0202
IP54 Protection for transmitted rotary handle
Type
1SDA…R1
IP54 protection for transmitted handle -RHE-
066587
Locks
Padlock on the circuit-breaker
Type
1SDA…R1
PLL Fixed lock with padlocks in ope position
066590
PLL Fixed lock with padlocks in open/closed position
066592
IP54
Fixed padlock
7
/52
1SDC210033D0202
Key lock n the circuit-breaker
Type
1SDA…R1
KLC Ronis key lock open, different keys, removable in open position
066599
KLC Ronis key lock open, same Type A keys, removable in open position
066600
KLC Ronis key lock open, same Type B keys, removable in open position
066601
KLC Ronis key lock open, same Type C keys, removable in open position
066602
KLC Ronis key lock open, same Type D keys, removable in open position
066603
KLC Ronis key lock pen, same keys, r movable in both position
066604
Key lock on the handle / front for locks
Type
1SDA…R1
RHL Ronis key lock open, different keys - RHx/FLD
066617
RHL Ronis key lock open, same Type A keys - RHx/FLD
066618
RHL Ronis key lock open, same Type B keys - RHx/FLD
066619
RHL Ronis key lock op n, same Type C keys - RHx/FLD
066620
RHL Ronis key lock open, same Type D keys - RHx/FLD
066621
RHL Ronis key lock op n/closed, different keys - RHx
066622
RHL Ronis key lock open/closed, different keys - FLD
069182
Key lock on the motor
Type
1SDA…R1
MOL-D Ronis key lock open, different keys
066629
MOL-S Ronis key lock open, same Type A keys
066630
MOL-S Ronis key lock open, same Type B keys
06 631
MOL-S Ronis key lock open, same Type C keys
066632
MOL-S R nis key lock open, same Typ D keys
066633
MOL-M Key lock against manual operation
066634
Front for FLD locks
Type
1SDA…R1
Fixed/Plug-in
Withdrawable
Front for FLD locks
066635
066636
Mechanical interlock
Type
1SDA…R1
MIR-H
066637
MIR-V
066638
Plate XT2 F
066641
Plate XT2 P/W
066642
Plate XT4 F
066645
Plate XT4 P/W
066646
Front for locks
Interlock
Key lock on the circuit-breaker
Key lock on the handle
Key lock on the motor
Ordering codes for XT4
Accessories
