41 Moulded Case Breakers 0115
ABB Low Voltage
Shrouds and terminals
Terminals for CuAl cables
Product Hierarchy 3000009
Order Code
FC CuAl 1x35...95mm
2
XT1 3 poles
1SDA067155R1
FC CuAl 1x2.5...95mm
2
XT2 3 poles
1SDA067163R1
FC CuAl 2x35...95mm
2
XT2 3 poles
1SDA067175R1
FC CuAl 1x70...185mm
2
XT2 3 poles
1SDA067167R1
FC CuAl 2x35...150mm
2
XT3 3 poles
1SDA067187R1
FC CuAl 1x90...185mm
2
XT3 3 poles
1SDA067179R1
FC CuAl 1x150...240mm
2
XT3 3 poles+ADP
1SDA067183R1
FC CuAl 1x2.5…185mm
2
XT4 3 poles
1SDA067191R1
FC CuAl 2x35...150mm
2
XT4 3 poles
1SDA067199R1
FC CuAl 1x2.5…185mm
2
XT4 3 poles
1SDA067191R1
FC CuAl 1x35...95mm
2
XT1 4 poles
1SDA067156R1
FC CuAl 1x2.5...95mm
2
XT2 4 poles
1SDA067164R1
FC CuAl 2x35...95mm
2
XT2 4 poles
1SDA067176R1
FC CuAl 1x70...185mm
2
XT2 4 poles
1SDA067168R1
FC CuAl 2x35...150mm
2
XT3 4 poles
1SDA067188R1
FC CuAl 1x90...185mm
2
XT3 4 poles
1SDA067180R1
FC CuAl 1x150...240mm
2
XT3 4 poles+ADP
1SDA067184R1
Terminals for CuAl cables
Product Hierarchy 3000006
FC CuAl 2x120mm
2
T5 400 3 poles
1SDA055028R1
FC CuAl 1x240mm
2
T5 400 3 poles
1SDA055020R1
FC CuAl 1x300mm
2
T5 400 3 poles
1SDA055024R1
FC CuAl 2x240mm
2
T5 630 3 poles
1SDA055032R1
FC CuAl 2x240mm
2
T6 630-S6 630 3 poles
1SDA023380R1
FC CuAl 3x185mm
2
T6 800-S6 800 3 poles
1SDA023384R1
FC CuAl 4x150mm
2
T6 1000 3 poles
1SDA060687R1
FC CuAl 4x240mm
2
T7-T7M 1250 3 poles
1SDA063112R1
FC CuAl 2x120mm
2
T5 400 4 poles
1SDA055029R1
FC CuAl 1x240mm
2
T5 400 4 poles
1SDA055021R1
FC CuAl 1x300mm
2
T5 400 4 poles
1SDA055025R1
FC CuAl 2x240mm
2
T5 630 4 poles
1SDA055033R1
FC CuAl 2x240mm
2
T6 630-S6 630 4 poles
1SDA023390R1
FC CuAl 3x185mm
2
T6 800-S6 800 4 poles
1SDA023394R1
FC CuAl 4x150mm
2
T6 1000 4 poles
1SDA060688R1
FC CuAl 4x240mm
2
T7-T7M 1250 4 poles
1SDA063113R1
Front terminals
Product Hierarchy 3000009
KIT F XT1 3 poles
1SDA066849R1
KIT F XT2 3 poles
1SDA066853R1
KIT F XT3 3 poles
1SDA066857R1
KIT F XT4 3 poles
1SDA066861R1
KIT F XT1 4 poles
1SDA066850R1
KIT F XT2 4 poles
1SDA066854R1
KIT F XT3 4 poles
1SDA066858R1
KIT F XT4 4 poles
1SDA066862R1
Front terminals
Product Hierarchy 3000006
KIT F T5 3 poles
1SDA055012R1
KIT F T6 630/800 - S6 630/800 3 poles
1SDA060421R1
KIT F T7-T7M 3 poles
1SDA063099R1
KIT F T5 4 poles
1SDA055013R1
KIT F T6 630/800 - S6 630/800 4 poles
1SDA060422R1
KIT F T7-T7M 4 poles
1SDA063100R1
Power distribution MCCBs
Type XT1 ... XT4 & T1 ... T7 accessories
7
/54
Ekip Display
Ekip LED Meter
1SDC210033D0202
Terminals
Type
1SDA…R1
3 pcs
4 pcs
6 pcs
8 pcs
F Front Terminals
066861
066862
066863
066864
EF Extended front ter inals
066877
066878
066879
066880
ES Extended spread front terminals
066901
066902
066903
066904
FC CuAl Terminals for CuAl cables 1x1...150mm
2
067191
067192
067193
067194
FC CuAl Terminals for CuAl cables 1x120...240mm
2
+ ADP
067195
067196
067197
067198
FC CuAl Terminals for CuAl cables 2x35...150mm
2
067199
067200
067201
067202
FC Cu Terminals for Cu cables
066917
066918
066919
066920
MC Multi-cable Terminals 6x2.5...35mm
2
066933
066934
066935
066936
R Rear adjustable Terminals
066949
066950
066951
066952
FB Flexibar Terminals
066969
066970
066971
066972
Accessories for electronic trip units
Type
1SDA…R1
Fixed/Plug-in
Withdrawable
Ekip Display
068659
068659
Ekip LED Meter
068660
068660
Ekip Com
068661
068662
PR212/CI Contactor control unit
050708
050708
HMI030 Interface on front of panel
063143
063143
CT External neutral
Type
1SDA…R1
CT External neutral of 40A
066975
CT External neutral of 63A
066976
T Neutro eesterno da 10 A
066977
CT External neutral of 160A
066978
CT External neutral of 250A
066979
Kit of Electronic trip unit auxiliary Voltage
Type
1SDA…R1
Fixed/Plug-in
Withdrawable
KIT of 24V DC auxiliary voltage for electronic trip units
066980
066981
KIT for PTC Connection
066982
066983
KIT for Ext NE Connection
066984
066985
KIT for PR212/CI Connection
066986
066987
KIT for external neutral voltage connection
069651
069652
Test and Configuration Unit
Type
1SDA…R1
Ekip TT - Trip Test Unit
066988
Ekip T&P - Programming and test Unit
066989
EF Terminal
FCCuAl Terminal
Ekip T&P unit
Ordering codes for XT4
Accessories
