Power distribution MCCBs
Type Tmax XT1 ... XT4 & T1 ... T7 accessories
4
4/43
email Telephone 02476 368500 Facsimile 02476 368401
Early auxiliary contacts - AUE
1SDA0 R1
Type T2-T3 Price T5-T6 Price T6 Price T7 Price
AUE - early contacts 51374 16.17 54925 15.84 60394 19.73 62112 66.06
Auxiliary position contacts - AUP
1SDA0 R1
Type T2-T3 Price T4-T5-T6 Price T7-T7M Price
AUP T2-T3 - 1 contact signalling circuit-breakers racked-in 51372 8.09 - - - -
AUP-I T4-T5 24V DC - 1 contact signalling circuit-breakers racked-in - - 54920 8.69 - -
AUP-I T4-T5 400V AC/DC - 1 contact signalling circuit-breakers racked-out - - 54918 7.91 - -
AUP-R T4-T5 24V DC - 1 contact signalling circuit-breakers racked-out - - 54921 8.69 - -
AUP-R T4-T5 400V DC - 1 contact signalling circuit-breakers racked-out - - 54919 7.91 - -
AUP T7-T7M 24V DC - - - - 62110 66.76
AUP T7-T7M 400V AC - - - - 62111 66.76
Adapters - ADP
1SDA0 R1
Type T4-T5-T6 Price
ADP - Adapters 5pin 55173 6.38
ADP - Adapters 6pin 54922 6.38
ADP - Adapters 12pin 54923 9.11
ADP - Adapters 10pin 54924 8.18
Testing extension
1SDA0 R1
Type T4-T5-T6 Price
5pin checking extension for blank tests on T4-T5-T6 P/W service release 55351 POA
6pin checking extension for blank tests on T4-T5-T6 P/W auxiliary contacts (1+1) service & residual current releases 55063 20.32
12pin checking extension for blank tests on T4-T5-T6 P/W auxiliary contacts 55064 40.64
5pin checking operator for blank tests on T4-T5-T6 P/W motor operator & early contacts 55065 33.87
Mechanical signals
Trip reset
1SDA0 R1
Type T7M Price
Trip reset 110...130 V AC / DC 62118 96.95
Trip reset 200...240 V AC / DC 62119 96.95
Mechanical operation counter
1SDA0 R1
Type T7M Price
Mechanical operation counter 62160 63.86
Electrical & Mechanical signals
1SDC210N32F0001
1SDC210N31F0001
1SDC210N33F0001
1SDC210N34F0001
B SF Section 4.5.indd 4/43 15/2/07 9:13:37 am
Electrical Signals
Early auxiliary contact
Product Hierarchy 3000006
Order Code
AUE T1-T2-T3 2 early contacts 1SDA051374R1
AUE T4-T5 250Vac/dc 2 early contacts 1SDA054925R1
AUE T6 250Vac/dc 2 early contacts 1SDA060394R1
AUE T7 400Va.c. 3 early contacts 1SDA062112R1
Aux position contact
AUP T2-T3 con inserted signalling 1SDA051372R1
AUP-I T4-T5-T6 con inserted signalling 1SDA054918R1
AUP-I T4-T5-T6 24 Vdc con inserted signalling 1SDA054920R1
AUP-R T4-T5-T6 24 Vdc con withdraw signalling 1SDA054921R1
AUP-R T4-T5-T6 con withdraw signalling 1SDA054919R1
AUP T7-T7M-X1 24Vd.c. (2INS+2TEST+2EXT) 1SDA062110R1
AUP T7-T7M-X1 250Va.c. (2INS+2TEST+2EXT) 1SDA062111R1
Adapters
ADP 5pin SOR/UVR RC T4-T5-T6 P/W 1SDA055173R1
ADP 6pin AUX T4-T5-T6 P/W 1SDA054922R1
ADP 12pin AUX T4-T5-T6 P/W 1SDA054923R1
ADP 10pin MOE AUE T4-T5-T6 P/W 1SDA054924R1
Mechanical Signals
Test Extension
Product Hierarchy 3000006
Order Code
Trip Reset 110..130Vac/dc T7 pushbutton operated 1SDA062118R1
Trip Reset 200..240Vac/dc T7 pushbutton operated 1SDA062119R1
Trip Reset
Operation Counter T7 pushbutton operated 1SDA062160R1
Motor Operat rs
Stored energy motor operator MOE
Product Hierarchy 3000009
Order Code
MOE XT2-XT4 24 Vdc 1SDA066463R1
MOE XT2-XT4 48...60 Vdc 1SDA066464R1
MOE XT2-XT4 110...125 Vac/dc 1SDA066465R1
MOE XT2-XT4 220...250 Vac/dc 1SDA066466R1
MOE XT2-XT4 380 Vac 1SDA066467R1
MOE XT2-XT4 480...525 Vac 1SDA066468R1
Stored energy motor operator MOE Product Hierarchy 3000006
MOE T4-T5 24 Vdc 1SDA054894R1
MOE T4-T5 48...60 Vdc 1SDA054895R1
MOE T4-T5 110...125 Vac/dc 1SDA054896R1
MOE T4-T5 220...250 Vac/dc 1SDA054897R1
MOE T4-T5 380 Vac 1SDA054898R1
MOE T6 24 Vdc 1SDA060395R1
MOE T6 48...60Vdc 1SDA060396R1
MOE T6 110...125 Vac/dc 1SDA060397R1
MOE T6 220...250 Vac/dc 1SDA060398R1
MOE T6 380Vac 1SDA060399R1
