Underfloor to desk solutions
88 |
In-screed flooring systems
A range of floor outlet boxes, fittings and
plates in galvanised steel, with choice of
PVC-U or steel ducting
Product information
•
3 and 4 compartments
(boxes come with extra divider to make 4 compartments)
•
Suitable for 65-85mm screed depth
•
Boxes for deeper floor screed available on request
•
Box tray lid suitable for standard 6mm floor finishes
•
For advice on box tray lids for non-standard floor finishes
please contact our Technical Team
•
Adjustable for box trim height
•
Grey moulded carpet trim for floor outlet boxes
•
Steel trims with various finishes available
•
Universal junction box with integral,
fully-reversible cable segregation
Blank end
code
description pack
USFB1
3 x 20mm KO 1
USFB25
3 x 25mm KO 1
Adaptor
code
pack
USFA1
1
Flat bend
(excluding connector)
code
description pack
USFF1
steel
1
HFP125BK
PVC-U
1
Vertical bend
(excluding connector)
code
description pack
USFV1
steel
1
HVP125BK
PVC-U
1
Steel screeding plate
code
pack
USFSP1
1
Note: Used in place of box lid
when screeding
Basic components
PVC or steel ducting
3 and 4 compartment
floor outlet box
Junction box
Vertical bend fitted to
segregated flush back box
Standard boxes suitable for
65 – 85mm screeded depth
Other trim finishes:
Floor boxes
can be provided with a variety of
trim finishes such as brass, stainless
steel and painted colours.
For further information please
contact the Technical Team on
+44 (0)1424 856688.
Floor materials
Marshall-Tufflex can supply floor outlet
boxes and junction boxes that are suitable
for different floor materials, such as marble,
stone or wood, or where a higher IP rating
is required. For more information on these,
please contact our Technical Team on
+44 (0)1424 856688.
Connector
code
pack
USFC1
1
3 Compartment steel duct
code
description pack
USFT25
225 x 25mm 1 x 2.5m
Standard floor box trim
GY
GY
: Grey
RAL7011 (floor box trim)
p262
Technical
Information
Floor outlet box
3 and 4 compartment
code size
pack
USF32
357 x 257mm 1
Universal junction box
(excluding adaptors)
code
size
pack
USJ3
269 x 234mm 1
Twin section PVC–Uduct
(three ducts required per run)
code
size
pack
MTU125
75 x 25mm 8 x 3m
Floor box lid assembly
code
description pack
UMLD1
Plastic
1
UMLD3
Steel
1
