UNDERFLOOR TO DESK SOLUTIONS
Underfloor to desk solutions
Power and data modules
| 93
p263
Technical
Information
Various configurations of
power and data outlets
Flexible in-feed options;
Weiland connectors or
hardwired tap offs, or a
20mm knockout
Power modules
Power module 2G indv fused
code
description pack
DM5001
3.15Amp
1
DM5003
5Amp
1
Power module 4G indv fused
code
description pack
DM5002
3.15Amp
1
DM5004
5Amp
1
Power & data modules
Module 2xpower 2xUSB
2xblank
code
description pack
DM5032
3.15Amp
1
DM5035
5Amp
1
Module 2xpower 2xUSB
2xCat 5e
code
description pack
DM5030
3.15Amp
1
DM5033
5Amp
1
Module 2xpower 2xUSB
2xCat 6
code
description pack
DM5031
3.15Amp
1
DM5034
5Amp
1
A range of power and data modules
ideal for under desk mounting.
Product information
•
High strength, fire retardant polycarbonate moulded modules
•
Aluminium RCBO units
•
The system can be fed directly from underfloor busbar
through a floor grommet to an RCBO unit to then feed
single or multiple modules as required
•
Can be fed from wall trunking, floor boxes,
grommets or powerpoles
•
For single use or modules can be interlinked
•
In-feed supply either by Wieland GST 18/3
connection or plug socket
•
Unswitched individually fused 3.15Amp or 5Amp sockets
•
2 and 4 gang options plus the ability to link modules
•
Twin USB points charge up to 5 x faster than your
standard PC USB port
•
Desk units comply with BS 6396 for Electrical Systems
in Office Furniture when powered from a plug socket
outlet and with BS 7671 when powered from a power
distribution network.
•
RJ45 data sockets in Cat 5e, Cat 6 or blank configuration options
•
All our sockets are ASTA certified
Our range of power modules and RCBOs can
be integrated to deliver a complete system from
underfloor to desk.
NEW
Unswitched individually
fused at 3.15 and 5Amp
