Underfloor to desk solutions
MT32 pre-wired underfloor distribution
| 91
Plate to accept 1 x 2 gang
accessory (M3.5 x 120.3mm)
code
description pack
UP732
* 4 comp
1
*Accessory overlaps adjacent plates
Plate to accept 2 x 1 gang
accessory (M3.5 x 60.3mm)
code
description pack
UP733
* 4 comp
1
*Accessory overlaps adjacent plates
13Amp 2 gang RCD
unswitched socket
code
description pack
UP660
3 comp Std
1
UP663
3 comp CE
1
Plate to accept 1 x 1 gang
accessory
code
description pack
UP631
3 comp
1
Powertrack tap off
•
32Amp tap-off pre-wired to MT32
male connector
•
3.0m and 5.0m leads, Standard or CE
•
Also 13Amp fused tap-offs
Should powertrack be the preferred method of underfloor
power supply, then combining powertrack with MT32’s
interlinked through floor boxes and/or slave units will provide
a far greater reach of floor area than can be achieved using
powertrack alone.
Accessory plates
13Amp 2 gang DP/TE
switched socket
code
description pack
UP651
3 comp
1
UP751
4 comp
1
13Amp 2 gang DP/TE
switched socket
clean earth
code
description pack
UP653
3 comp
1
UP753
4 comp
1
Blank plate
code
description pack
UP621
3 comp
1
UP721
4 comp
1
Data/voice plate 6 x RJ45
code
description pack
UP612
3 comp
1
Plate to accept 1 x 2 gang
accessory (M3.5 x 120.3mm)
code
description pack
UP632
3 comp
1
Plate to accept 2 x 1 gang
accessory (M3.5 x 60.3mm)
code
description pack
UP633
3 comp
1
Double plate with 2 x
13Amp 2 gang switched
socket
code
description pack
UP751D
4 comp
1
UP753D
4 comp CE
1
Plate to accept 1 x 1 gang
accessory
code
description pack
UP731
4 comp
1
(
SU)
Slave unit
Permits more floor
boxes to be fed from 1
powertrack tap off
Terminal or through floor box
Data/voice plate 4 x RJ45
code
description pack
UP610
3 comp
1
UP710
4 comp
1
Euro plate 2 gang
code
description pack
UP615
3 comp
1
*Adaptor plate required
Note:
Adaptor plates are not supplied
by Marshall-Tufflex
Data wave plate 4 x RJ45
code
description pack
UP617
3 comp
1
Plate dimensions
3 compartment = 185 x 95mm 4 compartment = 185 x 71mm
Plate material
Plates are manufactured from plain galvanised steel to match floor boxes.
