Light Sensitive Switches continued.

Mounting the Cell

To ensure correct operation of the light sensitive switch, the cell must

not be influenced by artificial light or direct solar radiation and should

be sheltered from dust and humidity. In case of disconnection of the

link between the cell and the light sensitive switch, the output of the

device will be switched on. Make sure the light sensitive switch is

unplugged before connecting the cell.

EE002

EE003

Type

Flush Mounting

Surface Mounting

Dimensions (mm)

89 x 48 x 32

25 x 25 x 20

Hole 25mm

Connection

Cable 1m 2 x 0.75mm

0.75 to 4mm

Protection Class

IP54

Working &

Storage

Temperature

-30ºC to +60ºC

Adjustment of the Working Level

The test position of the override selector 1 makes setting the

preset level easier by removing the ON and OFF delay.

Select the sensitivity range which suits your application (selector 1)

5 to 100 lux (low light level) application examples; public lighting,

shop windows, signals...

50 to 2000 lux (high light level) application examples; controls of

shades

At the appropriate moment of the day, put the selector 1 in test

position; turn the potentiometer 2 up to the switching point (the

indicator 4 lights); put the selector back to position ‘auto’ the normal

operating mode of the device.

Technical Specification

Electrical Specification

Voltage Rating

230V +10 -15% 50Hz

Consumption

1.5VA Max

Output

1 Voltage Free Changeover

Contact

Max Breaking Capacity

AC1 16A 250V~

Incandescent Lamp

2000W 230V~

Halogen Lamp

1000W 230V~

Fluorescent Lamp

Uncompensated

1000W 230V~

Compensated in Series (10μF)

1000W 230V~

// Compensated (15μF)

200W 230V~

Duo

1000W 230V~

Functional Characteristics

Sensitivity Range

5 to 100 lux, 50 to 2000 lux

Cycle

Weekly

Programs

8 Pre-defined Program

Program Setting

1 Minute Increments*

Accuracy

+6min / annum*

Operating Reserve

Lithium Battery Total of 3 Years

Supply Failure*

On and Off Delay

15 to 60s

Working Temperature

-30ºC to +60ºC (cell)

-10ºC to +50ºC (modular device)

Storage Temperature

-20ºC to +60ºC

Protection Class (cell)

IP54

Insulation Class

Connection Capacity

Modular Device

0.5 to 4mm

Cell

0.75 to 2.5mm

Max Length between Cell and

Modular Device

50m

Mounting of the Cell with 2

Screws

2.5mm

* EE171 only
