Type 2 / Class II Surge Protection Devices
SPN215*, SPN415* & SPN440*
SPN215D/R
SPN415D/R
SPN440D/R
Tested to
EN 61643-11 (VDE0675-6-11) 2002-12
SPD type
Type 2 according to EN 61643-11
SPD class
Class II according to IEC 61643-1
Type of connexion
Parallel connection
Maximum continuous operationg voltage U
c
Line / Neutal
≤ 255V
Neutral/ PE ≤ 275V
Voltage protection level
U
p
≤ 1kV
≤ 1kV
≤ 1.2kV
Nominal discharge current (8/20 μs)
[(DC+/DC-) --> PE]
I
n
5kA
5kA
15kA
Max. discharge current (8/20 μs) [(DC+/DC-) -->
PE]
I
max
15kA
15kA
40kA
Short-circuit withstand capability with max.
overcurrent protection
10kA - 32A
10kA - 32A
20kA - 32A
Operating temperature range
- 40°C ….+ 80°C
Indication of SPD disconnector
Green - Yellow - Red
Cross sectional area
min
1,5mm
2
solid / flexible
max
35mm
2
multi-stranded / 25mm
2
flexible
Tightening torque for terminals
4.0 Nm
Mounting on
35mm DIN rail in accordance with EN 60715
Enclosure material
grey thermoplastic, UL 94V-0
Degree of protection
IP20
Modular width (DIN 43880)
2
2
4
Auiliary contact. Voltage/ nominal current
(only applicable on the R suffix products)
230V/ 0.5A
12Vdc
10mA
