General Catalogue • Protection Devices • Technical
Type 1 & 2 Surge Protection Devices
SPA215*, SPA400*, SPA401*
SPA201
SPA401
Tested to
EN 61643-11 2002-12
SPD type / class
Type 1 + Type 2 / Class I
Energy-coordinated
protection effect on terminal
equipment
Type 1 + Type 2
Energy-coordinated
protection effect on
terminalequipment ≤ 5 m
Type 1 + Type 2 + Type 3
Type of connexion
Parallel connection
Type of power supply
system
TT / TN system
Type of protection
common and differential modes
Nominal voltage
U
N
230V/400V ac
Rated voltage
U
c
255V ac
Voltage protection level
U
p
≤ 1.5kV
TOV Voltage
U
T
440V / 5s
1200V / 200ms
Rated load current
I(L)
n/a
I(L-L)
n/a
Follow current interrupting
rating
I
fi
25kA rms
100A rms
Nominal discharge current
(8/20)
I
n
12.5kA
25kA
12.5kA
50kA
Impulse current (10/350)
I
imp
12.5kA
25kA
12.5kA
50kA
Max. rating of overcurrent
protection
fuse 160A gL / gG
MCCB n/a
160A
Short-circuit withstand
capability with max.
overcurrent protection
fuse 25kA rms
MCB n/a
Response time
t
A
≤ 100ns
Operating temperature
range
- 40°C ….+ 80°C
Indication of SPD
disconnector
Green/Red flag on L and N
Green/Red flag on L1, L2, L3 and N
Cross sectional area
min 1,5mm
2
solid / flexible
max 35mm
2
stranded / 25mm
2
flexible
Tightening torque for
terminals
4 Nm
Mounting on
35mm DIN rail in accordance with EN 60715
Enclosure material
grey thermoplastic, UL 94V-0
Degree of protection
IP20
Modular width
2
4
Weight
275 g
480 g
Approval marking
KEMA
