MCCBs & Moulded Case Switches
x160
MCCBs
Thermal settings
220/240V AC
IEC 60 947-2
380/415V AC
IEC 60 947-2
HDA
Icu 25 kA
18 kA
Ics 25 kA
18 kA
HHA
Icu 35 kA
25 kA
Ics 25 kA
20 kA
HCA
Icm -
2.8 kA
Icw -
2 kA - 1s
Thermal adjustment from 0.63 to 1 x I n
{
}
I n
16 - 50 A 63 - 80 A 100 - 125 A 160 A
I mag
600 A
1000 A 1500 A 1600 A
Magnetic adjustment fixed > 10 x I n
For DIN rail mounting, use HYA033H.
PUSHTOTRIP
TRIP
|
