Add-on Block
x160
Add-on block operating
Earth leakage current (I
৫
n
) and delay (
৫
t
) setting
N L1 L2 L3
N L1 L2 L3
incoming
outgoing
test button
CA
50%
electronic
ON
125A
250A
Characteristics
Reset button :
Signals add-on block tripping and must be reset before switching on the
installation.
Test button for RCD function :
Checks the electrical operating of the MCCB / Add-on block
association.
Mechanical test button :
Checks the mechanical operating of the MCCB / Add-on block
association.
LED signaling residual current level in the installation:
25% (orange) and 50% (red) I
৫
n
; green light to signal correct operating.
Remote tripping and advanced warning (50% I
৫
n
) signaling thanks to
these contacts:
When associated with MCCB, the add-on block provides an earth fault
protection and protects against electrical shocks by direct or indirect
contact.
The add-on blocks are protected against nuisance tripping caused by
transient voltages. It’s able to detect sinusoidal alternating currents and
residual pulsating direct currents ( A type ). It also avoids miss
tripping (HI type - High Immunity).
S (
৫
t)
A (I
৫
n
)
0.03 0.1 0.3 1
3
6
Inst.
OK OK OK OK OK OK
0.06 no OK OK OK OK OK
0.15 no OK OK OK OK OK
0.3 no OK OK OK OK OK
0.5 no OK OK OK OK OK
1
no OK OK OK OK OK
V
1
V
2
10
3
1 0,3
0,1
0,03
1
0,5 0,3
0,15
0,06
Inst.
I n (A)
t (s)
5
2
6
3
1 0.3
0.1
0.03
I n (A)
1
0.5
0.3 0.15
0.06
Inst.
t (s)
