Torroids
E
24.5
D
29
B
B
C
A
1.5
A
14
D
17
5.5
C
E
33.5
B
A1
A2
2.5
14
G
E
C
D
H
F
Reference Type Dimensions (mm)
A B C D E
HR701
Ø 35 35 92 86 43.5 74
HR702
Ø 70 70 115 118 60.5 97
HR703
Ø 105 105 158 162.5 84.5 140
HR704
Ø 140 140 218 200 103.5 183
HR705
Ø 210 210 290 295 150 265
Reference Type
Dimensions (mm)
A1 A1 B C D E F G H
HR830
70x175 70 175 176 260 85 225 22 40 7.5
HR831
115x305 115 305 239 400 116 360 25 50 8.5
HR832
150x350 150 350 284 460 140 415 28 50 8.5
A2
A1
B
D
E
C
F
Reference Dimensions (mm)
A1 A1 B C D E F
HR820
20 30 89 110 41 32 46
HR821
50 80 114 145 50 32 46
HR822
80 80 145 145 50 32 46
HR823
80 121 145 185 50 32 46
HR824
80 161 184 244 70 37 46
