47 / 381
2.12
General Catalogue • Enclosures
Rail Mounted Terminals
Description
To prewire incoming & outgoing
circuits in distribution boards.
Colour Code
Neutral = Blue
Earth = Green / Yellow
Phase = Beige
Phase
Rated Current
KXA02LH
24A
KXA04LH
32A
KXA06LH
41A
KXA10L
57A
KXA16L
76A
KXA35L
125A
KXB70LH
192A
Neutral
Rated Current
KXA02NH
24A
KXA04NH
32A
KXA06NH
41A
KXA10N
57A
KXA16N
76A
KXA35N
125A
KXB70NH
179A
End Plates Beige
Description
Width in mm
Cat ref.
For KXA02LH & KXA04LH
1.5
KWE01G
For KXA10L & KXA16L
-
KWE04G
For KXA35L
1.5
KWE03G
End Stops
Description
Width in mm
Cat ref.
Insulated material
8.5
KWB01
Connection Blocks in ≤ 125A Single Pole
Description
Width in mm
Cat ref.
Incoming 2 x 25mm
2
, Outgoing 4 x 16mm
2
2.5
K018
Incoming 2 x 35mm
2
, Outgoing 4 x 25mm
2
2.5
K037
Feed through Rail Mounted Terminals
Nominal
Min-Max
Rated voltage
Phase
Neutral
Earth
Cat ref.
Cat ref.
Cat ref.
2.5mm2
(0.5mm2 - 4mm2)
800V
KXA02LH
KXA02NH
KXA02E
4mm2
(0.5mm2 - 6mm2)
800V
KXA04LH
KXA04NH
KXB04E
6mm2
(0.5mm2 - 10mm2)
800V
KXA06LH
KXA06NH
KXB06E
10mm2
(1.5mm2 - 16mm2)
400V
KXA10L
KXA10N
KXA10E
16mm2
(1.5mm2 - 25mm2)
400V
KXA16L
KXA16N
KXA16E
35mm2
(6mm2 - 50mm2)
400V
KXA35L
KXA35N
KXB35E
70mm2
(16mm2 - 95mm2)
800V
KXB70LH
KXB70NH
KXB70E
K037
