2.9
orion plus GRP IP65 Enclosures & Accessories
Enclosure with plain door
Made of glass reinforced
polyester (GRP)
Colour : RAL 7035
FL 201B : RAL 7032
Body made out of one piece up
to height 800mm
IP 65 / door closed BS EN 60529
insulation class : II
These enclosures feature :
• Plain door equipped with
one or two locks with
triangular 8mm centres,
located out of the sealed area,
gasket directly moulded on
the door
• Studs in the back of the
enclosure for mounting plate
fastening
Options:
• Key lock
• Wall fixing brackets
• Mounting plate
• Equipment kits for modular
devices.
For full dimensions see page
2.19.
orion plus GRP Enclosures
Dimensions
No. of
Cat ref.
Cat ref.
Height x Width x Depth (mm)
locks
Plain door
Glazed door
300 x 250 x 160
1
FL201B ¹
-
350 x 300 x 160
1
FL204B
FL254B
500 x 300 x 200
2
FL209B
FL259B
500 x 400 x 200
2
FL213B
FL263B
650 x 400 x 200
2
FL216B
FL266B
650 x 500 x 250
2
FL221B
FL271B
800 x 600 x 300
2
FL229B
FL279B
1200 x 850 x 300
1
FL327B
FL527B
1 FL201B made of polycarbonate
orion plus GRP Enclosure Accessories
Description
Cat ref.
Key lock to be mounted on the triangular lock, supplied with 2 keys no 427 for h ≤ 800
FL96Z
Key lock to be mounted on the triangular lock, supplied with 2 keys no 427 for h ≤ 1150
FL98Z
Replacement lock 1 set of 2 locks with male square 8mm with 1 key
FL81Z
Replacement lock 1 set of locks double-bar 3mm with 1 key
FL97Z
Plastic wall fixing brackets delivered with fixing screws M 6x12 on enclosure set of 4 pieces
FL863Z
Depth adjustment slide for enclosures 300mm
FL672E
FL216B
FL96Z
FL81Z
FL97Z
FL863Z
