Prestige 3D
Dado & Skirting
Technical
Technical Hotline
+44 (0)1268 563720
613
CABLE MANAGEMENT
PERIMETER AND
DISTRIBUTION
CABLE CAPACITY
TYPE OF
CONDUCTOR SIZE
CABLE
FACTOR
COMPARTMENT 1
COMPARTMENT 2
COMPARTMENT 2 WITH
45MM DEEP BOX
COMPARTMENT 3
FULL TERM CSA (MM
2
)
1763
3828
610
1952
TERM AT 45% FILL (MM
2
)
793
1722
274
878
POWER CABLES
NUMBER OF CABLES AT 45% FILL
PVC stranded 1.5mm
2
8.6
92
200
31
102
2.5mm
2
12.6
62
136
21
69
4mm
2
16.6
47
103
16
52
6mm
2
21.2
37
81
12
41
DATA CABLES
NUMBER OF CABLES AT 45% FILL (A) AND FULL CAPACITY (B)
A
B
A
B
A
B
A
B
Cat 5E UTP 5.5mm dia.
30.2
26
58
57
126
9
20
29
64
Cat 5E STP 6.0mm dia.
36.0
22
48
47
106
7
16
24
54
Cat 6 UTP 6.5mm dia.
42.2
18
41
40
90
6
14
20
46
Cat 6 STP 7.0mm dia.
49.0
16
35
35
78
5
12
17
39
Cat6a
8.0mm dia
64.0
12
27
26
59
4
9
13
30
Cat 7
8.0mm dia
64.0
12
27
26
59
4
9
13
30
Prestige 3D Technical
– Dado & Skirting
Dimensions (mm)
Component Selection Guide
57mm
170mm
2
1
1
57mm
170mm
2
3
1
Profiles
Compartment CSA mm
2
1 = 1763
2 = 3828
3 = 1952
Assembly
Dado = 1.58 kg/m
Skirting = 1.60 kg/m
Wall Thickness
VP100 = 1.7mm
VP110 = 1.7mm
VP115 = 1.7mm
VP180 = 2.0mm
VP180WHI / CHA
VP110WHI / CHA
VP100WHI / CHA
VP110WHI / CHA
VP180WHI / CHA
VP110WHI / CHA
VP100WHI / CHA
VP115WHI / CHA
Dado
Skirting
Dado
Skirting
Data Trunking System
