MK Electric Catalogue No. 49

50 / 759

Telephone
Socket
Outlets
FLUSH
K422WHI 10
1 GANG
TELEPHONE MASTER
K427WHI 10
1 GANG
TELEPHONE SECONDARY
K4817WHI 10
1 GANG
RJ11 TELEPHONE SOCKET
K3540WHI 10
3 PIN WITH
TELEPHONE SYMBOL
(NON UK)
400NAT 10
IDC INSERTION TOOL
BS 6312 Pt 2
K4817 FCC 68
K3540
Accepts standard BS 546
2A 2 pin and earth plug where 2 pins are
used for telephone circuits and the earth
pin is used to ensure correct polarity.
BS 546:1950 where applicable
K422WHI
K427WHI
K4817WHI
K3540WHI
K3550WHI 1
SINGLE OUTLET
(IEC MALE)
K3551WHI 5
SINGLE OUTLET
(IEC FEMALE)
K3555WHI 1
SINGLE OUTLET
F-TYPE SATELLITE SOCKET
K3552WHI 5
TWIN TV/FM
DIPLEXER
Fully screened non isolated TV outlets
containing a combination of single,
TV/FM Diplexer, TV/FM/SAT Triplexer
and secondary telephone outlets for
use within digital TV systems and
interactive TV services.
K3552DABWHI 1
TWIN TV/FM
DAB DIPLEXER
K3553WHI 5
TRIPLE TV/FM/SAT
TRIPLEXER
K3553DABWHI 1
TRIPLE TV/FM DAB/SAT
TRIPLEXER
K3554DABWHI 1
QUAD TV/FM DAB/SATX2
QUADPLEXER
Single outlets for connection to a single
TV, FM or Satellite co-axial aerial lead.
TV/FM diplexer units for connection to a
single co-axial aerial lead with combined
TV and FM signals.
TV/FM and Satellite
Co-Axial Socket Outlets
FOR DIGITAL AND INTERACTIVE SERVICES
SCREENED, NON ISOLATED
FLUSH
MOUNTING BOXES
Minimum box depth 32mm
1 GANG: Flush: 866ZIC
Surface: K2181WHI
2 GANG: Flush: 886ZIC
Surface: K2183WHI
DIMENSIONS
1 GANG: 86 x 86mm
2 GANG: 86 x 146mm
FIXING CENTRES
1 GANG: 60.3mm
2 GANG: 120.6mm
PERFORMANCE
Refer to page 474 for technical
specification.
K3550WHI
K3551WHI
K3555WHI
K3552DABWHI
K3553WHI
K3552WHI
K3553DABWHI
K3554DABWHI
DAB PRODUCTS ARE NOT AVAILABLE IN IRELAND 50
