Euro Modular
Frontplates
K181WHI 10
1 GANG EURO FRONTPLATE
ONE MODULE
APERTURE SIZE 25 X 50MM
K182WHI 10
K182GRA 10
1 GANG EURO FRONTPLATE
TWO MODULE
APERTURE SIZE 50 X 50MM
K184WHI 10
K184GRA 10
2 GANG EURO FRONTPLATE
FOUR MODULE
APERTURE SIZE 100 X 50MM
K185WHI 10
3 GANG EURO FRONTPLATE
SIX MODULE
APERTURE SIZE 150 X 50MM
MOUNTING BOXES
Suitable for flush boxes to
BS 4662:2006 and surface boxes to
BS 5733:2010 Refer to appropriate
module for minimum box depth.
K185WHI MOUNTING BOX
35mm VTS8035 (For use with
Pinnacle and Premier cable
management systems) K2153WHI
30mm
FIXING CENTRES
1 GANG: 60.3mm 2 GANG: 120.6mm
BS 5733:2010 where applicable
Note: No grid required, modules just
clip into place
K184WHI
K181WHI
K5830WHI 1
K5830BLK 1
UK 1 GANG EURO 2 MODULE
13A 250V SHUTTERED
K5831WHI 10
K5831BLK 10
GERMAN 2P+E
16A 250V SHUTTERED
EURO 2 MODULE (NON UK)
K5832WHI 10
K5832BLK 10
AMERICAN 2P+E
15A 127V SHUTTERED
EURO 2 MODULE (NON UK)
K5830
MOUNTING BOX
35mm minimum
46mm (for extra wiring space)
DIMENSIONS
50 x 50mm
BS 1363 Pt2:1995
K5831
MOUNTING BOX
46mm
DIMENSIONS
50 x 50mm
IEC 60884-1:2006
K5832
MOUNTING BOX
35mm
46mm (for extra wiring space)
DIMENSIONS
50 x 50mm
SASO 2204:2003
K5833WHI 10
K5833BLK 10
UK 1 GANG EURO 2 MODULE
5A 250V SHUTTERED
K5834WHI 10
K5834BLK 10
FRENCH/BELGIAN 2P+E
16A 250V SHUTTERED
EURO 2 MODULE (NON UK)
K5837WHI 1
K5837BLK 1
USB CHARGING MODULE
EURO 2 MODULE
K5833
MOUNTING BOX
35mm minimum
46mm (for extra wiring space)
DIMENSIONS
50 x 50mm
BS 546:1950
K5834
MOUNTING BOX
46mm
DIMENSIONS
50 x 50mm
NF C61-314
K5837
MOUNTING BOX
35mm, 46mm (for extra wiring space)
DIMENSIONS
50 x 50mm
USB charging sockets, each capable of
supporting 2A charge (total of 2A).
IEC 60950-1
IEC 61000-6-1/3
Euro Power
Modules
K182WHI
K5830WHI
K5831WHI
K5832WHI
K5833WHI
K5834WHI
K5837WHI
K1090WHI 10
FLEX OUTLET FRONTPLATE
UNFUSED
Complete with three pairs of terminals, each
suitable for 2 x 2.5mm 2 conductors and a
1.5mm2 flexible cord.
A cord-grip is also fitted.
Frontplate thickness is 12.5mm.
Cable entry diameter is 11mm.
DIMENSIONS
86 x 86mm
FIXING CENTRES
60.3mm
BS EN 60670-22:2006
Blank Plates Flex Outlet
Frontplate
20 AMP
K3825WHI 10
1 GANG MOULDED
ARCHITRAVE
K3827WHI 10
1 GANG MOULDED
K3828WHI 10
2 GANG MOULDED
K5033WHI 1
METAL
K3825WHI
For use with 3921ZIC and K2151WHI
MOUNTING BOXES.
K5033WHI
For use with 5120ALM deep metal box.
DIMENSIONS
K3825WHI: 86 x 31mm
K3827WHI: 86 x 86mm
K3828WHI: 86 x 146mm
K5033WHI: 178 x 165mm
FIXING CENTRES
K3825WHI: 60.3mm
K3827WHI: 60.3mm
K3828WHI: 120.6mm
K5033WHI: 133mm
BS 5733:2010
K1090WHI
K3827WHI K3825WHI
K3828WHI
K5033WHI
