K3639WHI 1
12 MODULE
K3639WHI
K3636WHI 1
K3636GRA 1
6 MODULE
K3638WHI 1
K3638GRA 1
8 MODULE
K3636WHI
K3638WHI
K3631WHI 10
K3631GRA 10
1 MODULE
K3632WHI 10
K3632GRA 10
2 MODULE
K3633WHI 10
K3633GRA 10
3 MODULE
K3634WHI 10
K3634GRA 10
4 MODULE
All modules from the Grid Plus range
can be used with these frontplates.
DIMENSIONS
1 & 2 MODULE: 86 x 86mm
3 & 4 MODULE: 86 x 146mm
6 & 8 MODULE: 146 x 146mm
12 MODULE: 206 x 146mm
BS 5733:2010
K3631GRA
K3632WHI
K3634WHI
K3633GRA
Grid Plus Frontplates
ISOLATED
FLUSH
K3521WHI 10
SINGLE OUTLET
K3522WHI 10
TWIN OUTLET
WITH FM/TV DIPLEXER
MOUNTING BOXES
FLUSH
861ZIC (25mm)
SURFACE
K2140WHI
Provides safety isolation rated at
2000Va.c. between aerial lead
and socket.
Single outlet for connection to a single
TV or FM co-axial aerial lead.
Twin outlet with TV/FM diplexer for
connection to single co-axial aerial lead
with combined TV & FM signals.
DIMENSIONS
86 x 86mm
FIXING CENTRES
60.3mm
BS 5733:2010 where applicable
BS 3041:1977 IEC 169-2:1965
K3521WHI
K3522WHI
TV/FM and Satellite
Co-Axial Socket Outlets
NON ISOLATED
FLUSH
K3520WHI 10
SINGLE OUTLET
K3523WHI 10
TWIN OUTLET
K3525WHI 10
SINGLE F TYPE
SATELLITE SOCKET
K3525D1WHI 10
TWIN F TYPE
SATELLITE SOCKET
MOUNTING BOXES
FLUSH
861ZIC (25mm)
SURFACE
K2140WHI
Single outlet for connection to a single
TV or FM co-axial aerial lead. Twin
outlet for connection to each of two
separate TV/FM, co-axial aerial leads.
DIMENSIONS
86 x 86mm
FIXING CENTRES
60.3mm
BS 5733:2010
where applicable
BS 3041:1977
IEC 169-2:1965
K3520WHI
K3523WHI
K3525WHI
K3525D1WHI
