Switch Receivers and Repeater

K5420R

The 10AX Receiver/Repeater can function both as a 1 level repeater and as a

10AX Switch Receiver.

Dimensions

10AX Switch Receiver/Repeater – K5420R

Length: 175.5mm

Width: 50.3mm

Height: 33.25mm

K5420R

Standards and approvals

BS EN 60669-1, BS EN 60669-2-1,

ETSI EN301 489-1 & -3, ETSI EN61000-6-2,

ETSI EN300 220-3

TECHNICAL SPECIFICATION

ELECTRICAL

K5420R (WHEN USED AS A RECEIVER)

VOLTAGE RATING

250V a.c. 50Hz

CURRENT RATINGS

10AX – No de-rating when used on standard

magnetic ballast fluorescent loads.

TERMINALS

Terminal screw size:

Rated terminal screw torque:

0.5 Nm

TERMINAL CAPACITY

4 x 1mm²

3 x 1.5mm²

2 x 2.5mm²

PHYSICAL

OPERATING TEMPERATURE

-5°C to + 40°C

IP RATING

IP2XD

MAX. INSTALLATION ALTITUDE

2000 meters
