Transmitters
Standards and approvals
BS EN 60669-1, BS EN 60669-2-1,
ETSI EN301 489-1 & -3, ETSI EN61000-6-2,
ETSI EN300 220-3
TECHNICAL SPECIFICATION
PHYSICAL
AMBIENT OPERATING TEMPERATURE
-5°C to + 40°C
OPERATING FREQUENCY
868.3 MHz
IP RATING
IP2XD
MAX. INSTALLATION ALTITUDE
2000 meters
Dimensions
Transmitters: 86mm x 86mm
Fixing centres: 60.3mm
Mounting Transmitters
l
All Transmitters can be mounted to any
1-gang back box.
l
All can be mounted directly to the wall
surface – screws supplied.
l
All can be mounted to back boxes
– screws supplied.
l
Logic Plus
™
and Aspect type Transmitters
can also be mounted using supplied
adhesive pads
Features
l
Wireless and Batteryless – using
RF technology with ranges up to
30m indoors
l
Available in all MK wiring device
aesthetics
l
Quick and easy to install with no
need for cabling from the switch
to the lighting circuit
l
Robust Metalclad Plus
™
and
Masterseal Plus
™
available
l
400w and 10AX receiver/
repeaters available to cover most
installation needs
l
Switch Receivers are capable of
switching all lighting types
l
Each receiver can be controlled
by up to 32 switches/transmitters
Description
Echo
™
is an innovative range of entirely wireless, batteryless and self powered
switches, only available from MK Electric.
Wireless – allows for instant switch installation and location flexibility, reducing
disruption and cost, as there is no need to run switching cables.
Self-Powered – Innovative patented technology to ‘harvest’ energy means zero
maintenance as there are no batteries to change.
Ultimate Flexibility – Each receiver can be controlled by up to 32 switches/
transmitters.
MK Echo™ Technical
WIRING DEVICES
WIRELESS
