CABLELINK PLUS SINGLE PAN BOX
RANGE INTRODUCTION
Cablelink Plus Single Pan Box provides
an effective interface between services
beneath the floor and the office
environment.
Designed to offer robustness and constructed with a single piece
metal frame, the floorbox is available with 1, 3 and 4 compartments
and a choice of 70mm or 95mm box depths to cater for floor voids
of restricted space.
FEATURES & BENEFITS
TESTED TO EN 50085-2-2 TO ACCEPT 5000N LOAD
SUPPORTS CAT 6 & CAT 7
70mm through the use of the wave plate
SHALLOW VOIDS ACCOMMODATED
With 70mm pan depth
ADJUSTABLE DEVICE PLATE
To increase wiring space or greater plug top
clearance
COMPLIES WITH WIRING REGULATIONS
Provision of RCD protections supports IET 17th
Edition Wiring Regulations
SELF-CLOSING LID
In accordance with IEC 61534-22
FLOORBOXES ARE RATED IP2X IN ACCORDANCE
WITH BS EN 50085-1
WIDE RANGE OF POWER AND DATA ACCESSORY
PLATES
5 YEAR GUARANTEE
HOW TO SPECIFY
A range of 1, 2, 3 and 4 module single pan floorboxes designed to meet
EN50085-2-2. Product to incorporate a ratchet self-levelling system enable
rapid fitting of the frame and lid. Pan design to incorporate side knockouts
and compartment segregation and be available in both 70mm and 95mm
pan depths. Product to have a self-closing lid with locking option available.
Provision of RCD protection to support compliance to 17th Edition Wiring
Regulations.
