Floorbox
Box Size
Compartment
265 x 265mm
3
340 x 265mm
4
100–124MM DEPTH
CRMB265-3GRY* CRMB340-4GRY*
* Lockable option available – add suffix ‘L’ e.g CRMB265-3GRY
L
.
Floorbox lids must never be locked whilst in use. Box not supplied with key.
Supplied complete as
floorbox with 8mm recess lid. Smaller compartment floorbox available in Cablelink Plus Single Pan Box, see page 384 for more details.
For pre-configured options available – see page 381.
Cablelink Plus Modular Floorbox
The Modular Floorbox and Modules are ideal for use with the Interact Underfloor Power System – see page 371 for details.
Modular Floorbox Selector Guide
The Design Service enables bespoke customised floorboxes to be configured and delivered to meet the customers
individual requirements.
Step 1
Choose the number of compartments required (3 or 4 compartments)
Step 2
Choose whether the lid is lockable or not
Step 3
Choose which modules are required (See below for power options and next page for data / other options)
Step 4
What height are the modules to be fitted (100mm, 108mm, 116mm or 124mm)
Step 5
Do the power modules require tap-offs?
Step 6
If yes choose which type (See page 376 for tap-off options)
Serviced Power
Modules
Description
Left Hand Modules
Standard
Clean Earth
2G 13A SWITCH SOCKET
OUTLET
CRM11730*
CRM11730CE*
2G 13A SWITCH SOCKET
OUTLET NON STANDARD (T PIN)
CRM11730NS* CRM11730NSCE
2G 13A SOCKET OUTLET
CRM11731*
2G 13A 30MA PASSIVE RCD
SWITCH SOCKET OUTLET
CRM11735*
CRM11735CE
3G 13A SOCKET OUTLET
CRM11720
CRM11720CE
4G 13A SWITCH
SOCKET OUTLET
=
CRM11750
CRM11750CE
4G 13A SWITCH SOCKET
OUTLET NON STANDARD
(T PIN)
=
CRM11750NS CRM11750NSCE
4G 13A SOCKET OUTLET
=
CRM11751
=
Double module size with staggered arrangement to provide strain relief clearance for moulded plugs.
*
Add ‘
RH
’ suffix for Right Hand Module, e.g. CRM11730
RH
LEFT HAND MODULE –
CRM11730
RIGHT HAND MODULE
– CRM11730RH
l
Modules are available Left Hand
and Right Hand to achieve a
‘staggered’ arrangement
l
‘Staggered’ arrangement ensures
strain relief clearance for moulded
plug tops
l
Add ‘RH’ suffix for Right Hand
Module, e.g CRM11730RH
l
When four socket outlets are
required, order CRM11750
‘staggered’ arrangement
l
For more detail on how to order
and configure your Cablelink Plus
Modular Floorbox, please
see page 731-734
Modules have unique two
piece design to provide quick
and safe installation. Earthing
achieved through screwed
connection between base
and module plate.
Additional plates are available
via the Design Service,
see page 16
