Cablelink Plus Single Pan Box
SIDE KNOCKOUTS
l Pre-cut for fast and
simple installation
ONE PIECE FRAME
l Robust metal design
l 70mm pan depth is ideal
for shallow applications
and plenum floors
l 70mm and 95mm pan
depths available
WIDE RANGE OF POWER AND DATA PLATES
l Suitable for all applications
l Pre-configured options available for fast and simple installation on site
FLANGE FIXINGS
l Fast and simple installation
ROBUST CORD CAPS
l Designed for improved retention
LID
l Simple carpet cut out
l Easily removable and reversible for
improved accessibility
l Lid can be hinged from either of two sides
l Self closing in accordance with IEC 61534-22
HANDLE
l Designed
for improved
accessibility
OPTIONAL LOCKABLE LID
l Added security
when not
in use
OUTLET BOX COLOUR
l Grey (RAL 7011)
STAGGERED PLATE
l Provides strain relief
clearance for moulded
plug tops
l Device plate positioned
to provide 35mm wiring
space for 70mm deep
box and 45mm wiring
space for 95mm deep
box
l Stagger plate only
available within 3
compartment floorbox
COMPARTMENT
SEGREGATION
RATCHET LEVELLING SYSTEM
l Self levelling and rapid
fitting of frame and lid
OPTIONAL TETHER
l Added
security
l Eliminates lid losses
OPTIONAL CABLE RETAINERS
TESTED TO EN50085-2-2
TO ACCEPT 5000N LOAD
384
FLOOR SYSTEMSRAISED
CP Single Pan Box
