MK Electric Catalogue No. 49

378 / 759

Cablelink Plus Modular Floorbox
BLADES
l Quick release blades to secure
firmly in position for a “fit and forget”
installation
l No tools required for faster
installation
l Self adjusting blades – ensures
floorbox remains secure throughout
service life
l Fixes to floor thicknesses of
15-50mm
ONE PIECE MOULDED FRAME
l Simple ordering of product
l Faster installation
MODULES
l Design enables modules to be installed/removed whilst box is still in situ
l Left and right handed power plates provide plug top cable strain relief
l Pre-wired power modules available for quicker installation
l Cat 6, 6A and 7 and fibre solutions available
ROBUST CORD CAPS
l Designed for improved retention
LADDER DESIGN
l Modules can be positioned at different heights
(100-124mm range)
l Increased clearance for Cat 6, 6A and 7 patch leads,
transformer plugs and audio visual applications
l Improved module retention via easy fix clips
8MM RECESSED LID
l Simple carpet cut out
l Easily removable and reversible
for improved accessibility
l Can be hinged from either of two sides
l Self Closing in accordance with
BS EN 61534-22
HANDLE
l Designed for improved
accessibility
OPTIONAL LOCKABLE LID
l Added security when not
in use
OPTIONAL LID TETHER
l Added security
l Eliminates lid losses
SQUARE BOX OPTION
l 90º rotation of floorbox for
system flexibility**
OUTLET BOX COLOUR
l Grey (RAL 7011)
TESTED TO EN 50085-2-2
TO ACCEPT 5000N LOAD
MODULE RETAINER CLIP
Secures module to ‘ladder’ frame*
*When module retainer clip fitted, first rung
of ‘ladder’ frame can not be used.
**Only on 265 X 265 boxes. 378
FLOOR STETEMSRAISED
CP Modular
