MK Electric Catalogue No. 49

220 / 759

1131WHI 10
4 TERMINAL BLOCKS
10A
DIMENSIONS
OVERALL DIAMETER
81.5mm
DEPTH WITH COVER
22.5mm
TERMINAL CAPACITY
1131 6 x 1.5mm² conductors
1132 4 x 4mm² conductors
BS EN 60670-22 (where applicable)
1133WHI 10
3 TERMINAL BLOCKS
30A
DIMENSIONS
OVERALL DIAMETER
95mm
DEPTH WITH COVER
25mm
TERMINAL CAPACITY
Each terminal block accepts
up to 4 x 6mm² conductors
BS EN 60670-22 (where applicable)
1130WHI 10
3 TERMINAL
30A
Particularly suitable for taking spurs off un-cut
ring circuit conductors.
DIMENSIONS
86 x 64 x 31mm
TERMINAL CAPACITY
Each terminal accepts
3 x 4mm² conductors.
CABLE ENTRIES
Two opposite ‘through’ entries are ‘open’.
Eight further knockouts are provided.
BS EN 60670-22 (where applicable)
1132WHI 10
3 TERMINAL BLOCKS
30A
DIMENSIONS
OVERALL DIAMETER
81.5mm
DEPTH WITH COVER
22.5mm
TERMINAL CAPACITY
1131 6 x 1.5mm² conductors
1132 4 x 4mm² conductors
BS EN 60670-22 (where applicable)
Junction Boxes
1131WHI 1132WHI 1133WHI 1130WHI
220
WIRING DEVICES
Ancillary Products
BOXES AND ANCILLARY
PRODUCTS
