219 / 759
5114WHI
1
FLUSH MOUNTED
WITH NEON
5115WHI
1
SURFACE MOUNTED
WITH NEON
5116WHI
1
SURFACE MOUNTED
WITH NEON
4724WHI
10
20A DP SWITCH
WITH KEYTAG
4700WHI
10
SPARE KEYTAG
MOUNTING BOXES
FLUSH
866ZIC
SURFACE
2160WHI
The MK Energy Saving Switch provides a
simple and effective way of reducing electricity
consumption while increasing safety in buildings
where appliances may be left on in unoccupied
rooms.
By removing the keytag the power is switched off
eliminating the need to switch off each individual
light or appliance. A neon locator light on the
switch unit makes it easy to locate when entering
darkened rooms.
DIMENSIONS
86 x 86mm
FIXING CENTRES
60.3mm
BS EN 60669-1:1999
995WHI
10
FLUSH MOUNTING
Fitted with 2 amp fuse-link to BS 1362.Terminals
will accommodate 2.5mm² conductors.
995WHI
Includes earthing facilities and is suitable for
mounting in BS 4662 boxes. The removable fuse
carrier is fully recessed and total projection of the
plate is only 4.2mm. A knockout on the underside
is provided so an M3.5 screw or hook engages
with a tapped lug on the box (for hanging a wall
clock).
DIMENSIONS
995WHI
86 x 86mm
FIXING CENTRES
995WHI
60.3mm
BS 5733:2010
Triple Pole &
Neutral Switches
METAL FLUSH
32 AMP
SURFACE
Energy Saving
Switch
FLUSH
Clock
Connectors
FUSED
MOUNTING BOX
FLUSH
5268ALM
These products have a utilisation category of AC22 – rated operational current (Ie),32A – rated operational
voltage (Ue), 440V. They are suitable for switching mixed resistive and inductive loads including moderate
overloads.
5114
is also available in Albany Plus finishes (page 178).
All switches may be locked in the ‘ON’ or ‘OFF’ position with 1 the use of the MK Padlock K2000.
5116
is available in Metalclad Plus version (page 230).
TERMINAL CAPACITY
16mm
2
conductors. On surface mounted versions the earth terminal is fitted on base of box.
DIMENSIONS
5114
203 x 140mm
5115
182 x 118 x 82mm
5116
137 x 76 x 53mm
KNOCKOUTS
5115
5 x 25mm. Two top and bottom, one in back
5116
6 x 20mm. Wiring space limits recommended cable size to 6mm
2
.
BS EN 60947-3:1999
4724WHI
4700WHI
5114WHI
5115WHI
5116WHI
995WHI
MK Electric Catalogue
219
WIRING DEVICES
Technical Hotline
+44 (0)1268 563720
Ancillary Products
BOXES AND ANCILLARY
PRODUCTS
