MK Electric Catalogue No. 49

216 / 759

QFB1WHI 20
1 GANG
QFB2WHI 10
2 GANG
All round flange for a flush fit. One
piece moulded lug automatically
snaps into place. No rear
projections. Clamp device on cable
entry. Will accommodate partition
thickness between 6mm and 16mm.
Earth terminal facility.
BS 4662:2006
DRY LINING
35MM
FLUSH
K2134WHI 10
1 GANG 20MM DEEP
FOR LOGIC PLUS™
ACCESSORIES
K2133WHI 10
2 GANG 20MM DEEP
FOR LOGIC PLUS™
ACCESSORIES
FIXING CENTRES
1 gang: 60.3mm
2 gang: 120.6mm
BS 5733:2010
K2061WHI 5
1 GANG
K2062WHI 5
2 GANG
DIMENSIONS
K2061: 88 x 88mm
K2062: 88 x 148mm
FIXING CENTRES
K2061: 60.3mm
K2062: 120.6mm
BS 5733:2010
K2031WHI 10
FOR 1 GANG
LOGIC PLUS™
POWER ACCESSORIES
K2172WHI 5
FOR 2 GANG
LOGIC PLUS™50 AMP
DP SWITCHES
Knockouts provided in sides and
base.
K2172: Earth terminal fitted in base
of box.
DIMENSIONS
K2031: 87 x 87mm
K2172: 87 x 148mm
FIXING CENTRES
K2031: 60.3mm
K2172: 120.6mm
BS 5733:2010
K2025WHI 5
FOR MOUNTING
TWO 1 GANG
LOGIC PLUS™
ACCESSORIES
This box has two slots in base
with 60.3mm and 120.6 fixing
centres for fitting over BS 4226
flush boxes. Knockouts provided
for cable entry.
Includes integral dividing fillet.
DIMENSIONS
86 x 172 mm
BS 5733:2010
K2131WHI 5
1 GANG
10 CLAMPS
K2132WHI 5
2 GANG
12 CLAMPS
Clamps accept 20mm
sealing pots.
DIMENSIONS
1 gang: 92 x 92mm
2 gang: 92 x 152mm
FIXING CENTRES
1 gang: 60.3mm
2 gang: 120.6mm
BS 5733:2010
QFB/IG1 20
1 GANG WITH
INTUMESCENT GASKET
QFB/IG2 10
2 GANG WITH
INTUMESCENT GASKET
QFB/IG1 & QFB/IG2
Pre-fitted with intumescent
gaskets to give fire protection, in
accordance with BS 476-2:1987. In
a fire situation, a chemical reaction
will occur with the intumescent
material. The void behind the wiring
device will be filled, providing
protection against the passage
of fire.
BS 4662:2006
2031WHI 10
FOR 1 GANG
POWER ACCESSORIES
SQUARE CORNERS
Knockouts in base and sides for
cable entry.
DIMENSIONS
87 x 87mm
FIXING CENTRES
60.3mm
BS 5733:2010
2140WHI 10
FOR 1 GANG
POWER ACCESSORIES
SQUARE CORNERS
Knockouts are provided in base
and sides for cable entry
DIMENSIONS
1 gang: 87 x 87mm
2 gang: 87 x 148mm
FIXING CENTRES
1 gang: 60.3mm
2 gang: 120.6mm
BS 5733:2010
44MM
SURFACE
32MM
SURFACE
Mounting
Pattresses
FLANGE BOXES
45MM
FLUSH
40MM
SURFACE SURFACE
DUAL BOX
38MM
SURFACE
MI CABLE BOXES
37MM
SURFACE
Moulded Boxes
216
WIRING DEVICES
BOXES AND ANCILLARY
PRODUCTS
Boxes
