MK Electric Catalogue No. 49

226 / 759

K3077WHI 10
1 GANG DP
WITHOUT BOX
K3046WHI 5
2 GANG DP
WITHOUT BOX
K2977ALM 5
1 GANG DP WITH
DUAL EARTH
TERMINALS
K2977D5ALM 1
1 GANG DP WITH DUAL
EARTH TERMINALS
WITHOUT BOX
K2977D6ALM 1
1 GANG DP WITH RED
ROCKER AND DUAL
EARTH TERMINALS
K2946ALM 5
2 GANG DP
K2946D5ALM 1
2 GANG DP
WITHOUT BOX
K2946D6ALM 1
2 GANG DP WITH
RED ROCKERS
Earth terminal fitted in boxes.
DIMENSIONS
1 gang 86 x 86 x 51mm
2 gang 86 x 146 x 51mm
KNOCKOUTS
1 gang 6 x 20mm – Two in one side and one in
each of the other three sides. One in base.
2 gang 8 x 20mm – Three in top two in bottom
sides and one in each end. One in base.
SPARE BOXES
1 gang K829ALM* K899ALM
2 gang K830ALM* K897ALM
(*without side knockouts)
All boxes have a base knockout.
BOXES
BS 5733:2010
SOCKET
BS 1363-2:1995
HIGH INTEGRITY EARTHING
One gang switchsockets, two gang outboard
switchsockets, two gang integrated USB
switchsockets and two gang unswitched sockets
are fitted with two earth terminals to provide a
double earth facility for use when installations
require a high integrity protective connection as
specified within BS 7671:2008
DOUBLE POLE SWITCHING
All switchsockets have double pole switching
(neutral makes first, breaks last).
K2945ALM 5
2 GANG DP
WITH OUTBOARD
ROCKERS AND DUAL
EARTH TERMINALS
K2945D5ALM 5
2 GANG DP
WITH OUTBOARD
ROCKERS AND DUAL
EARTH TERMINALS
WITHOUT BOX
K2945D6ALM 1
2 GANG DP
WITH RED OUTBOARD
ROCKERS AND DUAL
EARTH TERMINALS
K3045WHI 5
2 GANG DP
WITHOUT BOX
WITH OUTBOARD
ROCKERS AND DUAL
EARTH TERMINALS
K2435ALM 1
13A DP KEY
OPERATED SOCKET
Earth terminal fitted in boxes.
DIMENSIONS
86 x 146 x 51mm
KNOCKOUTS
8 x 20mm – Three in top two
in bottom sides and one in
each end. One in base.
MOUNTING BOX
K830ALM* K897ALM
(*without side knockouts)
All boxes have a base
knockout.
BOXES
BS 5733:2010
SOCKET
BS 1363-2:1995
K2477ALM 5
1 GANG DP
WITH NEON AND DUAL
EARTH TERMINALS
K2477D6ALM 1
1 GANG DP
WITH NEON,
RED ROCKER AND DUAL
EARTH TERMINALS
K2446ALM 5
2 GANG DP
WITH NEONS
K2446D6ALM 1
2 GANG DP
WITH NEONS
AND RED ROCKERS
DP
13 AMP
Switchsocket
Outlets
K2946D6ALM
K2977ALM
K2977D6ALM
K2946ALM
WITH OUTBOARD
ROCKERS
13 AMP
K2945D6ALM
K2945ALM K3077WHI
K3046WHI
K3045WHI
1 GANG DP
K2435ALM
K2446D6ALM
K2477ALM
K2446ALM
K2477D6ALM
WITH NEONS
13 AMP
All units are supplied with backboxes (except WHI, D5 products and Blankplates)
2 GANG DP
WITH 2 X USB
CHARGING PORTS
DUAL EARTH
13 AMP
K2943D5ALM
K2943D5WHI
K2943D5ALM 1
2 GANG DP WITH DUAL
EARTH TERMINALS
WITH INTEGRAL USB
CHARGING WITHOUT
BOX
K2943D5WHI 1
2 GANG DP WITH DUAL
EARTH TERMINALS
WITH INTEGRAL USB
CHARGING WITHOUT
BOX
Features 2 USB charging
sockets, each capable of
supporting 2A charge
(total of 2A)
BS5733: 2010
MOUNTING BOX
K897ALM
K897WHI
226
WIRING DEVICES
Metalclad Plus™
