BETA Monitoring
Monitoring of Electrical Values
5
TT6 priority switches
13/17
Siemens ET B1 · 10/2008
*
You can order this quantity or a multiple thereof.
13
■
Overview
In the mixed operation of electric hot water and electric storage
heaters, the priority switch interrupts the charging procedure of
the storage heater if hot water is required during the low-tariff
time, thus limiting the connected load in compliance with BTO § 6.
The control circuit terminals must be sealable.
■
Benefits
Reduction of the connection fee, which depends on the maximum
load to be supplied (BTO, German Federal Regulation on Tariffs
§ 6 Section 4), when used in systems with continuous-flow heaters
and electric storage heaters where the continuous-flow heaters
are switched with priority.
■
Technical specifications
■
Selection and ordering data
■
Dimensional drawings
■
Schematics
Switching example: 5TT6 10
In mixed operation of electric hot water and electric storage heaters,
the priority switch interrupts the charging procedure of the storage
heater if hot water is required during the low-tariff time, thus
limiting the connected load.
5
TT6 101
5
TT6 102
5
TT6 103
Standards
EN 60669 (VDE 0632), BTO § 6 Section 4
Rated control current
I
c
A
40
54
6 ... 40
(
Current corresponds to the rated operational power of the
continuous-flow heater).
Rated frequency
Hz
50
Response currents
A
13
23
6
(
Continuous rise not permissible)
Rated operational power
For continuous-flow heaters
Up to 230 V AC
kW 9
12
1.5 ... 9
Up to 3 × 230 V AC
kW 27
36
4.5 ... 27
Rated impulse withstand voltage U
imp
kV > 2.5
Rated operational voltage U
e
V AC 250
Rated operational current
I
e
At U
e
= 230 V AC
A
1
Terminals
±
screw (Pozidriv)
1
Conductor cross-sections
•
Coil
For conductor
cross-sections up to
mm
2
10
•
Contacts
For conductor
cross-sections up to
mm
2
2
× 2.5
Permissible ambient temperature
°C -20 ... +40
Resistance to climate
Acc. to DIN 50016
FW 24
U
e
I
e
Response
currents
MW DT Order No.
Price
per PU
PG PU PS*/
P. unit
Weight
per PU
approx.
V AC A
A
Unit(s) Unit(s) kg
5
TT6 101
Priority switches
For continuous-flow heaters up to 27 kW
230 40
13
1
}
5
TT6 101
027 1
1
0.100
For continuous-flow heaters up to 33 kW
230 54
23
1
B
5
TT6 102
027 1
1
0.100
For electronically controlled
continuous-flow heaters up to 27 kW
230 40
6 ... 40 1
}
5
TT6 103
027 1
1
0.100
5
TT6 101, 5TT6 102, 5TT6 103
5
TT6 101, 5TT6 102, 5TT6 103
18
45
86
44
55
5
I2_06544b
i
11
12
k
11
12
k
i
>
I
5
TT6 101, 5TT6 102, 5TT6 103
A2
2 4 6
A1
A1
14 12
A2
5
TT3 983
11
1 3 5
k
i
v
L1 L2 L3
L1
L1
L1 L2 L3 N
N
N
5
TT3 080
I2_07042c
5
TT6101
or
5
TT6102
or
5
TT6103
Electric
storage
heater
EVU release
Continuous-
flow water
heater
3 230
V AC
230
V AC
3 400
V AC
