BETA Switching
Timers
7
LF6, 5TT1 3 timers for buildings
9/17
Siemens ET B1 · 10/2008
*
You can order this quantity or a multiple thereof.
9
■
Selection and ordering data
■
Dimensional drawings
U
e
I
e
U
c
MW DT Order No.
Price
per PU
PG PU PS*/
P. unit
Weight
per PU
approx.
V AC A AC V AC
Unit(s) Unit(s) kg
Stairwell lighting timers
With switch for continuous light and push-to-lock
knurling wheel setting,
setting range 0.5 ... 10 minutes
For 3-wire circuit, L-momentary contact,
not resettable
250
16
230
1
}
7
LF6 110
027 1
1
0.085
For 4-wire circuit, L-momentary contact,
resettable, or 3-wire circuit, N-momentary contact,
resettable
250
16
230
A
7
LF6 111
027 1
1
0.085
With warning by flashing prior to switch-off,
for 4-wire circuit, L-momentary contact,
resettable, or 3-wire circuit, N-momentary contact,
resettable
250
16
230
}
7
LF6 113
027 1
1
0.085
Lighting timers
With switch for continuous light and push-to-lock
knurling wheel setting,
with warning by flashing prior to switch-off,
setting range 0.5 ... 10 minutes,
4-
fold extension of runtime by pressing the
pushbutton for 1 second,
for 4-wire circuit, L-momentary contact,
or 3-wire circuit, N-momentary contact
250
16
230
1
B
7
LF6 114
027 1
1
0.085
Energy-saving timers
With switch for continuous light and push-to-lock
knurling wheel setting,
with warning by flashing prior to switch-off,
setting range 3 ... 60 minutes,
switch off by pressing pushbutton second time as
with remote control switch,
for 4-wire circuit, L-momentary contact, resettable,
or 3-wire circuit, N-momentary contact, resettable
250
16
230
1
A
7
LF6 115
027 1
1
0.085
Timers for fans up to 200 VA
With switch for continuous light and push-to-lock
knurling wheel setting,
setting range 0.5 ... 10 minutes,
for delayed switch-on of fan
250
16
230
1
B
7
LF6 112
027 1
1
0.085
ECG control switches for ECG dynamic
With transparent cap, with switch for continuous light
and position indication, setting range 1 ... 10 minutes,
with warning through dimming prior to switch-off,
direct current output 1 ... 10 V for control of 20 ECG
dynamic mounting depth 55 mm
250
10
230
2
B
5
TT1 303
027 1
1
0.130
7
LF6 110 7LF6 111
7
LF6 112
7
LF6 113
7
LF6 114
7
LF6 115
5
TT1 303
7 24
44
64
I2_10911
45
67
90
I2_06708c
36
T
A2
14 13
A1
+ --
43
64
90
5
B1 B2
45
