Overview
The 5TE1 switch disconnectors are available from 100 A to
200
A in 3 and 4-pole versions and can be used as main
switches, repair switches, outgoing feeder switches, as well as
emergency system interrupters.
The series corresponds to the requirements of IEC/EN 60947-3
and its key features are its compact and robust design, high
short-circuit strength, high DC switching capacity and
comprehensive accessories.
Its small footprint means it is easy to install in all types of
enclosures, distribution boards and control cabinets.
The devices are approved to UL 508 and KEMA certified.
■
Benefits
•
Transparent enclosures ensure that the contact position is
always visible
•
Contacts with double breaks ensure reliable insulation
characteristics
•
Can be locked in the OFF position to allow for maintenance
work
•
With a red knob and yellow cap, it can also be used as an
emergency system interrupter.
■
Technical specifications
5
TE1 .1 5TE1 .2 5TE1 .3 5TE1 .4
Standards
IEC/EN 60947-3, UL 508
Approved acc. to
UL 508 for the following types: 5TE1 320, 5TE1 330,
5
TE1 340, 5TE1 420, 5TE1 430 and 5TE1 440.
UL File No. E302554
Rated operational current
I
e
Per conducting path at U
e
= 400 V DC A
100
125
160
200
With utilization category AC-21A
415
V DC A
100
125
160
200
500
V DC A
100
125
160
200
690
V DC A
100
125
160
200
Rated operational current
I
e
Per conducting path at U
e
= 400 V DC A
100
125
160
200
With utilization category AC-22A
415
V DC A
100
125
160
200
500
V DC A
100
100
160
200
690
V DC A
63
63
160
200
Rated operational current
I
e
Per conducting path at U
e
= 400 V DC A
80
125
160
With utilization category AC-23A
415
V DC A
80
125
160
500
V DC A
50
125
125
690
V DC A
40
63
80
Rated operational current
I
e
2
poles in series
110
V DC A
100
160
With utilization category DC-23A
2
poles in series
220
V DC A
--
100
4
poles in series
220
V DC A
100
160
Rated operational voltage U
e
V AC Acc. to UL: 480, acc. to IEC: 690
Rated insulation voltage U
i
V AC 690
Rated impulse withstand voltage U
imp
2000
m
kV
8
Impulse test voltage
At sea level
kV
12.3
Max. rated operational power
At U
e
= 400 V DC kW 44
69
88
With utilization category AC-23A
415
V DC kW 46
72
92
500
V DC kW 35
86
86
690
V DC kW 36
60
76
Thermal rated current
I
th
At 40 °C, 50 °C and 60 °C
A
100
125
160
200
Rated making capacity
At 415 V AC-23A
A
1875
3200
4000
Rated breaking capacity
At 415 V AC-23A
A
1000
1920
2400
Rated short-circuit making capacity
I
cm
Per conducting path At U
e
= 400 V DC kA 10
415
V DC kA 10
500
V DC kA
6.7
690
V DC kA
6.7
Rated short-time withstand current
I
cw
Per conducting path
0.25
s kA
5
6
(
peak value)
1
s
kA
2.5
3
Rated conditional short-circuit current
At U
e
= 400 V DC kA 50
With back-up protection with back-up fuse
415
V DC kA 50
With identical rated current
500
V DC kA 50
690
V DC kA 33
33
20
18
Capacitive load
At 400 V
kVar
50
60
77
97
Number of poles
2/3/4
Rated power dissipation P
v
Per pole
VA 2.9
4.5
6.5
10
Frequency
Hz
50/60
Conductor cross-sections
•
Solid and stranded
mm
2
6 ... 50
--
•
AWG cables
AWG 10 ... 1/0
8
•
Copper busbars
mm
2
--
Max. 20 x 6
Service life
Electrical
Switching
cycles
1500
1000
Mechanical
20000
10000
Acc. to UL 508
I
n
A
--
80
100
125
UL 508 General Use 480 V
FLA (full load amperes)
A
--
28
34
40
UL 508 manual motor controller 230 V
Power
hp
--
10
25
30
UL 508 manual motor controller 480 V
Power
hp
--
20
15
15
UL 508 short circuit at 480 V
With Class H or K5 fuses
kA --
10
With J fuses
kA --
50
