SR60 Busbar Systems
Distribution board components
5/6
Siemens ET B1 · 10/2008
*
You can order this quantity or a multiple thereof.
5
Dimensions
Conductor
cross-section
Tightening
torques
DT Order No.
Price
per PU
PG PU PS*/
P. unit
Weight
per PU
approx.
mm
2
Nm
Unit(s) Unit(s) kg
Extension terminals
For 12 x 5 mm busbars
(
busbar not included in the scope
of supply)
(1
set = 2 units)
6.0
A
8
JK3 201
046 1
set 10 sets 0.100
Terminals for circular conductors
20
mm × 5 mm to
30
mm × 10 mm 150 ... 240
A
8
US19 41-2BB00
143 1 6
0.307
Dimensions
(
H x W)
DT Order No.
Price
per PU
PG PU PS*/
P. unit
Weight
per PU
approx.
mm × mm
Unit(s) Unit(s) kg
Assembly kits
Comprising touch protection cover
and 4 supports
Cutout width
For three-phase busbar systems
216
mm
300
× 250
A
8
GK4 801-2KK13
039 1
1
0.500
466
mm
300
× 500
A
8
GK4 801-2KK23
039 1
1
0.700
716
mm
300
× 750
A
8
GK4 801-2KK33
039 1
1
0.900
216
mm
450
× 250
A
8
GK4 801-3KK13
039 1
1
0.650
466
mm
450
× 500
A
8
GK4 801-3KK23
039 1
1
0.900
716
mm
450
× 750
A
8
GK4 801-3KK33
039 1
1
1.150
Supports for blanking covers
For blanking cover,
mounting on busbar
(2
units required for each section of blanking cover)
B
5
SH3 536
016 1
4/160 0.040
Blanking covers
Mounting on 5SH3 536 support for blanking covers
Length
Height
1000
mm 202 mm
A
5
SH3 537
016 1
2
0.075
