SR60 Busbar Systems
Distribution board components
5/4
Siemens ET B1 · 10/2008
*
You can order this quantity or a multiple thereof.
5
■
Selection and ordering data
Dimensions
DT Order No.
Price
per PU
PG PU PS*/
P. unit
Weight
per PU
approx.
mm
Unit(s) Unit(s) kg
Longitudinal stays
For mounting the assembly kits in unequipped
distribution boards, two longitudinal stays are required
for each assembly kit width
1
set = 2 stays
Height
600
A
8
GK4 851-4KK00
039 1
set
1
set
1.000
750
A
8
GK4 851-5KK00
039 1
set
1
set
1.300
900
A
8
GK4 851-6KK00
039 1
set
1
set
1.500
1050
A
8
GK4 851-7KK00
039 1
set
1
set
1.800
1200
A
8
GK4 851-8KK00
039 1
set
1
set
2.080
1350
A
8
GK4 852-8KK00
039 1
set
1
set
2.340
Busbar supports
For busbars with a busbar thickness of 5 or 10 mm
and a busbar height of 12, 15, 20, 25 or 30 mm
For mounting on longitudinal stays, with fixing screws
Three-phase
A
8
GK9 711-0KK03
039 1
1
1.100
N/PE busbar supports
N
For flat copper profiles
For 5/10 mm busbars
A
5
SH3 540
016 1
1
0.059
Cu busbars
Cu cross-section
Length
12
× 5 mm, current intensity 250 A 250
A
8
GK9 731-0KK10
039 1
5
0.100
500
A
8
GK9 731-0KK20
039 1
5
0.330
750
A
8
GK9 731-0KK30
039 1
5
0.500
1000
A
8
GK9 731-0KK40
039 1
5
0.660
1250
A
8
GK9 731-0KK50
039 1
5
0.830
20
× 5 mm, current intensity 320 A 250
A
8
GK9 733-0KK10
039 1
5
0.290
500
A
8
GK9 733-0KK20
039 1
5
0.570
750
A
8
GK9 733-0KK30
039 1
5
0.850
1000
A
8
GK9 733-0KK40
039 1
5
1.120
1250
A
8
GK9 733-0KK50
039 1
5
1.470
30
× 5 mm, current intensity 450 A 250
A
8
GK9 735-0KK10
039 1
5
0.400
500
A
8
GK9 735-0KK20
039 1
5
0.750
750
A
8
GK9 735-0KK30
039 1
5
1.460
1000
A
8
GK9 735-0KK40
039 1
5
2.170
1250
A
8
GK9 735-0KK50
039 1
5
2.880
30
× 10 mm, current intensity 630 A 250
A
8
GK9 736-0KK10
039 1
5
0.750
500
A
8
GK9 736-0KK20
039 1
5
1.720
750
A
8
GK9 736-0KK30
039 1
5
2.600
1000
A
8
GK9 736-0KK40
039 1
5
3.400
1250
A
8
GK9 736-0KK50
039 1
5
4.600
Cover profiles for busbars
Busbar thickness 5 mm
Width 12 mm
1000
A
8
US19 22-2CA00
143 1
10 0.200
Width 15, 20, 25, 30 mm
1000
A
8
US19 22-2AA00
143 1
10 0.156
Busbar thickness 10 mm
Width 12, 15, 20, 25, 30 mm 1000
A
8
US19 22-2BA00
143 1
10 0.105
