BETA Protecting
SR60 Busbar Systems
Distribution board components
5/5
Siemens ET B1 · 10/2008
*
You can order this quantity or a multiple thereof.
5
Conductor
cross-section
DT Order No.
Price
per PU
PG PU PS*/
P. unit
Weight
per PU
approx.
mm
2
Unit(s) Unit(s) kg
Infeeds,
connection modules, three-phase
For 5/10 mm busbars with cover
With screwless terminals,
200
mm long, 20 mm wide
1.5 ... 16
N
A
5
SH3 538
016 1
5
0.181
With screw terminals
200
mm long, 54 mm wide
6 ... 50
A
8
US19 21-1BA00
143 1
1
0.397
200
mm long, 81 mm wide
35 ... 120
A
8
US19 21-1AA00
143 1
1
0.607
(
shown without cover in the illustration,
but cover included in delivery)
150 ... 300
C
5
SH3 535
016 1
1
1.657
Dimensions
Conductor
cross-section
Tightening
torques
DT Order No.
Price
per PU
PG PU PS*/
P. unit
Weight
per PU
approx.
mm
2
Nm
Unit(s) Unit(s) kg
Terminals for circular conductors
8
US19 21-2AA00
Busbar thickness 5 mm
1.5 ... 16
}
8
US19 21-2AA00
143 1 100
0.001
4 ... 35
}
8
US19 21-2AB00
143 1 50
0.046
16 ... 70
}
8
US19 21-2AD00
143 1 50
0.072
16 ... 120
}
8
US19 21-2AC00
143 1 50
0.107
Busbar thickness 10 mm
1.5 ... 16
}
8
US19 21-2BA00
143 1 100
0.020
4 ... 35
}
8
US19 21-2BB00
143 1 50
0.040
16 ... 70
}
8
US19 21-2BD00
143 1 50
0.070
16 ... 120
}
8
US19 21-2BC00
143 1 50
0.100
Terminals for one busbar
Busbar thickness 5 mm
Width 12 mm
1.5 ... 6
1.4
A
8
JH4 102
046 1 10
0.010
16 ... 35
3.0
A
8
JH4 104
046 1 10
0.030
16 ... 70
6.0
A
8
JH4 105
046 1 10
0.030
16 ... 95
10.0
A
8
JH4 106
046 1 10
0.070
25 ... 120
10.0
A
8
JK3 061
046 1 10
0.090
