CI insulated enclosures
Accessories for busbar enclosures
2010
CA08103002Z-EN
www.eaton.comPrepared enclosures
20/41
Accessories forbusbarenclosuresPreparedenclosures
For use with
busbars
mm
Terminal
capacity for
flat strip
mm
Operating
current of the
flat strip
I
e
A
Terminal
capacity
Round
conductor
mm
2
Part no.
Article no.
Price
See price
list
Std. pack
Notes
Busbar terminals
For connection of flat
strip or round conductor
Cu 12 x 5
3
x 9 x 0.8
100
16 - 35
16 - 25
K12X5-1
002281
10
off
Cu 12 x 5
3
x 9 x 0.8
10
x 16 x 0.8
100
400
25 - 120
25 - 95
K12X5-2
002282
Cu 20 x 5
3
x 9 x 0.8
6
x 9 x 0.8
4
x 16 x 0.8
6
x 16 x 0.8
100
160
200
250
35 - 70
35 - 50
K20X5
002286
Cu 20 x 5
3
x 9 x 0.8
6
x 9 x 0.8
4
x 16 x 0.8
6
x 16 x 0.8
10
x 16 x 0.8
11
x 21 x 1
100
160
200
250
400
630
35 - 240
35 - 185
K20X10
002283
Cu 20 x 10
3
x 9 x 0.8
6
x 9 x 0.8
4
x 16 x 0.8
6
x 16 x 0.8
10
x 16 x 0.8
11
x 21 x 1
100
160
200
250
400
630
35 - 185
35 - 95
Cu 20 x 15
3
x 9 x 0.8
6
x 9 x 0.8
4
x 16 x 0.8
6
x 16 x 0.8
10
x 16 x 0.8
11
x 21 x 1
100
160
200
250
400
630
35 - 70
35 - 50
Cu 20 x 10-15
Cu 20 x 5-15
3
x 9 x 0.8
11
x 21 x 1
100
630
35 - 300
35 - 240
K20X15
002284
Connection for flat strip and copper busbar
Cu 2 x 30 x 10 2 x 50 x 12
–
–
K30X10L
081977
3
off
For main conductor
L1, L2, L3
Cu 1 x 30 x 10 50 x 12
–
–
K30X10PEN
084350
2
off
For protective or neutral
conductor PE, N, PEN
Cu 3 x 40 x 10 2 x 50 x 12
–
–
K40X10
086723
3
off
For main conductor
L1, L2, L3
Cu 1 x 30 x 10 3 x 9 x 0.8 - 11
x 21 x 1
100
630
–
AW3040L-K20
089096
5
off
In combination with
busbar terminals K20X5,
K20X10, K20X15
Cu 2 x 30 x 10
Cu 2 x 40 x 10
3
x 9 x 0.8 - 11
x 21 x 1
100
630
–
AW30PEN-K20
091469
5
off
In combination with
busbar terminals K20X5,
K20X10, K20X15
Notes
1)
Terminal capacity:
⊙solid
stranded
flexible with ferrule
Terminals AK... ￫Chapter 16, Accessories for control panels
K..., AW...-K20
HPL20041EN
