Eaton Industrial Switchgear - Xboard Optimal switchgear enclosure

42 / 140

20/38 CI insulated distribution boards
Distribution board terminal enclosure
2010 CA08103002Z-EN
Prepared enclosures
PreparedenclosuresDistributionboard terminalenclosure
Distribution board terminal enclosure
• Distribution board enclosure with terminals and fitted gland plate
• External connection for round and solid sector conductors, internal for copper strip,
conversion kits to round and solid sector conductors ￫Chapter 16: Accessories for control panels
• Large knockouts at top, and apertures for wedge-lock fasteners
• Closed side walls with full area knockouts
• Fitting of cable supports in the distribution board with wedge-lock fastener
• Protection type IP65 (gland plates at bottom)
• Stepped cable grommet
• Split gland plate
• Cables can be inserted from the front
• Enclosure KST... with fitted gland plate
• Subsequent conversion of CI distribution board enclosures and CI individual enclosures possible
Rated
uninterrupted
current
Pole Enclosure
depth
Terminal capacity
(stranded
conductors) mm2
Strip terminal
(max.) mm
Basic enclosure
Mounting system
Part no.
Article no.
Price
See price
list
Std. pack
Iu Devices ( Number )
A mm mm2
160 4 225 1 x 16...95
6 x 9 x 0.8 KST34-200
L5-CI43
K95/... (4 or 5)
K95/4/KST34
025031
1 off
5 K95/5/KST34
027404
250 4 1 x 35...150
2 x 16...70
6 x 16 x 0.8
KST34-200
L5-CI43
K150/... (4 or 5)
K150/4/KST34
029777
5 K150/5/KST34
032150
160 4 225 1 x 16...95
6 x 9 x 0.8
KST43-200
L5-CI43
K95/... (4 or 5)
K95/4/KST43
041642
5 K95/5/KST43
039269
250 4 1 x 35...120
2 x 16...70
6 x 16 x 0.8
KST43-200
L5-CI43
K150/... (4)
K150/4/KST43
034523
400 4 225 1 x 50...240
2 x 25 x 120
10 x 16 x 0.8
KST44-200
L5-CI43
K240/... (4 or 5)
K240/4/KST44
044015
5 K240/5/KST44
046388
375
45 45
200
50
250
250
100
110 110
35
375
375
230
75 75
25
375
K...KST HPL20038EN
