19/52 Circuit-breakers, fuses
LV h.b.c. accessories
2010 CA08103002Z-EN
LVh.b.c.accessories
Fuse link For use with Connection Part no.
Article no.
Price
See price
list
Std. pack
Size
Busbar tag shroud 1 pole
00 GSTA00-160-1P Connection top or bottom ZBS-GSTA00-1P
119006
2 off
1 GSTA1-1P Connection top or bottom ZBS-GSTA1-1P
119007
2 off
3 GSTA3-1P Connection top or bottom ZBS-GSTA3-1P
119008
2 off
Busbar tag shroud 3 pole
00 GSTA00-160 Connection top or bottom ZBS-GSTA00
014411
10 off
1 GSTA1 Connection at the top
ZBS-GSTA1
082800
10 off
1 GSTA1 Connection at the bottom ZBSU-GSTA1
082804
10 off
2 GSTA2 Connection at the top ZBS-GSTA2
082801
5 off
2 GSTA2 Connection at the bottom ZBSU-GSTA2
082805
10 off
3 GSTA3 Connection at the top
ZBS-GSTA3
082802
1 off
3 GSTA3 Connection at the bottom ZBSU-GSTA3
082806
10 off
For use with Part no.
Article no.
Price
See price
list
Std. pack
Clip set
able to be fitted later, adjustable
snap fitting to two top hat rails to IEC/EN 60715 (35 mm)
For intervals between busbar centres of 100 - 125 mm
– GSTA00-160 C-GSTA00
040922
5 off
One set comprises 3 clamp-type terminals.
Terminal range 1 x (70 - 150) mm² Cu/Al GSU1, GST…1 PSK1
038734
1 off
Terminal range 1 x (120 - 240) mm² Cu/Al GSU2, GST…2 PSK2
043480
1 off
Terminal range 1 x (120 - 300) mm² Cu/Al GSU3, GST…3 PSK3
048226
1 off
Sets of double clamp-type terminals
One set comprises 3 double clamp-type terminals
Terminal range 2 x (70 - 95) mm² Cu/Al GSU1, GST…1 PSK12
041107
1 off
Terminal range 2 x (120 - 150) mm² Cu/Al GSU2, GST…2 PSK22
045853
1 off
Terminal range 2 x (120-240) mm² Cu/Al GSU3, GST…3 PSK32
050599
1 off
Insulating surround for fuse switch-disconnectors
For compensation between the GA... protective cover and the device (for use in the CI insulated distribution board
system)
– GST00 B-GST00-40-60/CI/1
224553
5 off
ZBS...-GSTA..., PSK... HPL19052EN
